Lexicon, Inc.
DC-2/MC-1 Serial Communications Protocol
Application Header:
Command DC_RESP_EFFECT_PARAM_DEF 0x86
Data Count 4
Application Data:
Data[0] EffectId
Data[1] ParamId
Data[2] MaxValue
Data[3] Value
7.3.10.5 Data Description
EffectId:
Data Type:
Max:
ParamId:
Data Type:
Max:
MaxValue: Maximum Value allowed for this parameter.
Data Type:
Max:
Value: The Current Value for this parameter.
Data Type:
Max:

7.3.11 Get Effect Parameter Values

Request to DC-2/MC-1 for an effect's parameter values. DC-2/MC-1 will respond with "Effect Parameter
Values Packet".
7.3.11.1 Command Packet Description
Application Header:
Command DC_CMD_GET_EFFECT_PARAM_VALUES
Data Count 1
Application Data:
Data[0] EffectId
7.3.11.2 Data Description
EffectId:
Data Type:
Max:
7.3.11.3 Data Validation:
The EffectId must be a valid Effect Id. If it is not the DC-2/MC-1 will respond with a NAK packet and
error code DC_ERR_ INVALID_EFFECT_ID.
7.3.11.4 Effect Parameter Values Response Packet
0x04
nn
nn
nn
nn
Unsigned 8 bit integer.
Set by the Effect Count in the "Unit Configuration Packet".
Unsigned 8 bit integer.
Set by the Parameter Count in the "Effect Definition Packet".
Unsigned 8 bit integer
255
Unsigned 8 bit integer
MaxValue(in this Packet)
Unsigned 8 bit integer.
Set by the Effect Count in the "Unit Configuration Packet".
Printed on: 10/19/00
0x1D
0x01
nn
20 of 44
