DC-2/MC-1 Serial Communications Protocol

11 Appendix C DC-2/MC-1 IR-Codes

Function
Off 19
On 18
OSD Off 02
FrontPanel Off 03
LIGHT N/A
FrontPanel On 04
OSD On 05
Menu Up 01
Done 0A
SPARE 06
Select 08
Menu Down 1D
Mute 15
Effect + 1A
Effect - 1B
Volume + 17
Volume - 16
VCR 13
DVD 12
V-DISC 11
TV 10
AUX 0F
CD 0E
TUNER 0D
TAPE 0C
Dolby 20
THX 21
Logic7 22
dts 23
2-Chan On/Off 24
Party 25
TV Matrix 26
Music 27
SPARE 28
SPARE 29
SPARE 2A
SPARE 2B
SPARE 2C
SPARE 2D
SPARE 2E
SPARE 2F
null 30
Hex
Code Shift Functions
Trigger Off
Trigger On
Menu Back Off
reserved
reserved
Menu Back On
Fade Front
Balance Left
SPARE
Balance Right
Fade Rear
Full Mute
Center Bal/Fad
EQ Off
Volume +5dB
Volume –5dB
Bass +
Treble +
Tilt +
Loudness On
Bass -
Treble -
Tilt -
Loudness Off
Nightclub
Concert Hall
Church
Cathedral
Expansion Ports*
Panorama
Mono Logic
Music Surround
SPARE
SPARE
SPARE
SPARE
SPARE
SPARE
SPARE
SPARE
null
Hex Code Rec Function
99 Zone-2: Off
98 Zone-2: On
82 Reserved
83 Reserved
-
84 Reserved
85 Status Menu
81 Reserved
8A Z-2: Bal Left
86 SPARE
88 Z-2: Bal Right
9D Reserved
95 Z-2: Mute
9A Lock the LOCK
9B Reserved
97 Z-2: Volume +
96 Z-2: Volume -
93 R/Z-2: VCR
92 R/Z-2: DVD
91 R/Z-2: V-DISC
90 R/Z-2: TV
8F R/Z-2: AUX
8E R/Z-2: CD
8D R/Z-2: TUNER
8C R/Z-2: TAPE
A0 Z-2 Vol: -30dB
A1 Z-2 Vol: -20dB
A2 Z-2 Vol: -10dB
A3 Z-2 Vol: +00dB
A4 Volume: -30dB
A5 Volume: -20dB
A6 Volume: -10dB
A7 Volume: +00dB
A8 SPARE
A9 SPARE
AA SPARE
AB SPARE
AC SPARE
AD SPARE
AE SPARE
AF SPARE
B0 null
