7.3.3.3 DC-2/MC-1 Response
The KeyCode is processed as a valid IR code. No acknowledgment will be sent from DC-2/MC-1.
7.3.3.4 Data Validation
The KeyCode data will be verified as a legal IR code. If the Code is not valid the DC-2/MC-1 will not
respond.

7.3.4 Get DC-2/MC-1 Unit Configuration

Request to DC-2/MC-1 for it's current unit configuration. DC-2/MC-1 will respond with "Unit
Configuration Packet". The HOST should use this information to determine if any information saved by the
HOST is current.
7.3.4.1 Command Packet Description
Application Header:
Command DC_CMD_GET_CONFIG
Data Count 0
Application Data:
N/A
7.3.4.2 DC-2/MC-1 Unit Configuration Response Packet
Application Header:
Command DC_RESP_UNIT_CONFIG
Data Count 25
Application Data:
Data[0] ProductId
Data[1] Software Type
Data[2] Software Level
Data[3] Software Major Revision
Data[4] Software Minor Revision
Data[5] Protocol Major Revision
Data[6] Protocol Minor Revision
Data[7] Total Number of System Parameters
Data[8] Total Number of Effects
Data[9] TimeStamp[0]
Data[10] TimeStamp[1]
Data[11] TimeStamp[2]
Data[12] TimeStamp[3]
Data[13] TimeStamp[4]
Data[14] TimeStamp[5]
Data[15] TimeStamp[6]
Data[16] TimeStamp[7]
Data[17] TimeStamp[8]
Data[18] TimeStamp[9]
Data[19] TimeStamp[10]
Data[20] TimeStamp[11]
Data[21] TimeStamp[12]
Data[22] TimeStamp[13]
Data[23] TimeStamp[14]
Data[24] TimeStamp[15]
0x15
0x00
0x80
0x19
nn
nn
nn
nn
nn
nn
nn
nn
nn
ch
ch
ch
ch
ch
ch
ch
ch
ch
ch
ch
ch
ch
ch
ch
0x00
