DC-2/MC-1 Serial Communications Protocol

7.3.22 Set Record/Zone2 Input

Sets the Record/Zone 2 input. If Record/Zone2 was inactive, this command will set the input then activate
the Record/Zone 2 function.
7.3.22.1 Command Packet Description
Application Header:
Command DC_CMD_SET_REC_INPUT
Data Count 1
Application Data:
Data[0] InputId
7.3.22.2 Data Description
InputId:
Data Type:
Max Value:
Conversion:
7.3.22.3 DC-2/MC-1 Response
7.3.22.4 Data Validation:
The InputId must be a valid Input Id. If it is not the DC-2/MC-1 will respond with a NAK packet and error
code DC_ERR_ INVALID_INPUT_ID. If the input selection is disallowed(input blocked, digital input not
selected...) DC-2/MC-1 will respond with a NAK packet and error code DC_ERR_INVALID_INPUT If
the input is assigned the DC-2/MC-1 will respond with an ACK Packet.

7.3.23 Clear Record/Zone2 Input

Clears or Unassign's the Record/Zone 2 input. If Record/Zone2 is active, this command will unassign the
zone 2 input and set the record outputs to the main input source.
7.3.23.1 Packet Description
Application Header:
Command DC_CMD_CLEAR_REC_INPUT
Data Count 1
Application Data:
Data[0] InputId
7.3.23.2 Data Description
InputId:
Data Type:
Max Value:
Conversion:
7.3.23.3 DC-2/MC-1 Response
7.3.23.4 Data Validation
The InputId must be a valid Input Id. If it is not the DC-2/MC-1 will respond with a NAK packet and error
code DC_ERR_ INVALID_INPUT_ID. If the input is unassigned the DC-2/MC-1 will respond with an
ACK Packet. If the record/zone 2 function was not active the DC-2/MC-1 will respond with an ACK
packet.
Unsigned 8 bit Integer
7
Input Id's are defined in Appendix D Input Id's
Unsigned 8 bit Integer
7
Input Id's are defined in Appendix D Input Id's
0x25
0x01
nn
0x26
0x01
nn
