VLT® AQUA Drive FC 202
Design Guide
Speed
Reference
Start (18)
Freeze ref (27)
Speed up (29)
Speed down (32)
Illustration 93: Speed Up/Down

12.1.4 Wiring Configuration: Feedback

Table 109: Analog Current Feedback Transducer (2-wire)
Drive
+24 V
12
13
+24 V
D IN
18
D IN
19
COM
20
D IN
27
D IN
29
D IN
32
D IN
33
37
D IN
+10 V
50
+
A IN
53
A IN
54
-
4-20 mA
COM
55
A OUT
42
COM
39
U - I
A 54
168 | Danfoss A/S © 2020.09
Parameters
Function
Parameter 6-22 Terminal 54 Low Current
Parameter 6-23 Terminal 54 High Current
Parameter 6-24 Terminal 54 Low Ref./Feedb. value
Parameter 6-25 Terminal 54 High Ref./Feedb. Value
*=Default value
Notes/comments:
D IN 37 is an option.
Basic I/O Configurations
Setting
4 mA*
20 mA*
0*
50*
AJ300847815559en-000101 / 130R0337
