Table 152: Ordering Numbers for dU/dt Filters for 525–690 V Drives
Drive ratings [V]
525–550 551–690
[kW] [A] [kW] [A]
5.5 9.5 1.1 1.6
7.5 11.5 1.5 2.2
– – 2.2 3.2
3.0 4.5
4.0 5.5
5.5 7.5
7.5 10
7.5 14 11 13
11 19 15 18
15 23 18.5 22
18.5 28 22 27
30 43 30 34
37 54 37 41
45 65 45 52
– – – –
55 87 55 62
55 87 75 83
75 113 90 108
90 137 – –
– – – –
Dedicated A3 enclosures supporting footprint mounting and book style mounting. Fixed shielded cable connection to the drive.
1
13.2.14 Order Numbers for VLT® Common-mode Filters MCC 105
Table 153: Order Numbers and Dimensions for Common-mode Filters
Enclosure size Order number
A and B 130B3257
C1 130B7679
C2, C3, C4 130B3258
D 130B3259
208 | Danfoss A/S © 2020.09
Filter current rating [V]
460/480@60 Hz,
500/525@50 Hz
[A]
15
40
80
105
160
Core dimensions (mm [in])
W w
60 (2.36) 43 (1.7)
82.8 (3.25) 57.5 (2.26)
102 (4.0) 69 (2.71)
189 (7.44) 143 (5.63)
575/600@60 Hz 690@50 Hz
[A] [A]
13 10
32 27
58 54
94 86
131 108
H h
40 (1.57) 25 (0.98)
45.5 (1.79) 20.6 (0.81)
61 (2.4) 28 (1.1)
126 (4.96) 80 (3.15)
How to Order a Drive
Order number
IP00 IP20 IP54
N/A 130B7367 N/A
(1)
130B2835 130B2836 130B2837
130B2838 130B2839 130B2840
130B2841 130B2842 130B2843
130B2844 130B2845 130B2846
Weight [kg (lbs)]
d
22.3 (0.88) 0.25 (0.55)
33 (0.30)
37 (1.46) 1.6 (3.52)
37 (1.46) 2.45 (5.4)
