  • Page 1 Manual 01/20 MN05006001Z-EN SmartWire-DT SWD module IP20...
  • Page 2 No part of this manual may be reproduced, stored in a retrieval system, or transmit- ted in any form or by any means, electronic, mechanical, photocopying, micro-film- ing, recording or otherwise, without the prior written permission of Eaton Industries GmbH, Bonn.
  • Page 3 Danger! Dangerous electrical voltage! Before commencing the installation • Disconnect the power supply of the device. • Built-in devices for enclosures or cabinets must only be run and operated in an installed state, desk-top devices or portable • Ensure that devices cannot be accidentally retriggered devices only when the housing is closed.

  • Page 5: Table Of Contents

    Device Status ................25 2.5.7 Detailed descriptions..............25 Digital module EU5E-SWD-8DX ........... 26 2.6.1 INTRODUCTION ................26 2.6.2 Surface mounting................. 26 2.6.3 Engineering .................. 26 2.6.4 Installation ..................27 2.6.5 Parameterization ................27 2.6.6 Fieldbus-specific characteristics........... 27 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 6 Analog module EU5E-SWD-4AX ..........49 2.12.1 INTRODUCTION ................49 2.12.2 Surface mounting................. 49 2.12.3 Engineering .................. 49 2.12.4 Installation..................50 2.12.5 Parameterization ................50 2.12.6 Fieldbus-specific characteristics ..........50 2.12.7 Programming ................52 2.13 Analog module EU5E-SWD-2A2A..........54 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 7 Safety-related applications ............95 4.3.4 Feedback loop ................99 4.3.5 Measures for higher safety categories ........100 4.3.6 Application for EN ISO 13849-1 and EN 62061......103 4.3.7 Applications in North America............104 Installation ..................105 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 8 Data profiles................. 152 6.10.3 Acyclic data PKE-SWD-CP ............153 Pilot devices M22-SWD…............155 INTRODUCTION ................155 M22-SWD front mount ..............155 7.2.1 Surface mounting................. 156 7.2.2 Engineering .................. 156 7.2.3 Installation..................160 7.2.4 Commissioning ................161 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 9 Surface mounting................. 213 Engineering .................. 213 Installation ..................215 Commissioning ................216 Exchange of modules..............216 Device Status ................216 Programming................217 9.8.1 Outputs ..................217 9.8.2 Diagnostics................... 217 SmartWire-DT universal module M22-SWD-NOP and M22- SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 10 Color tables M22-SWD-LED(C)-RGB..........257 13.4.1 Color table profile 1..............257 13.4.2 Color table profile 2...5..............257 13.5 Reference table: Part no., SmartWire-DT vs. Eaton catalog number ..................258 13.6 SWD module interoperability requirements......... 259 13.6.1 SmartWire-DT coordinators ............259 13.6.2 Fieldbus description files .............
  • Page 11 M22-SWD connections ..............275 13.7.7 Bus termination resistor, switch cabinet leadthroughs....278 13.7.8 Enclosure bushings: plug, socket..........279 13.7.9 Coupling, plug ................280 13.7.10 SWD-Basemodules for signal towers .......... 281 13.7.11 NZM circuit-breakers-..............284 Index.................... 287 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 12 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 13: About This Manual

    (I-REL)” "EU5E-SWD-4D4D-R module ✓ ✓ 09/2017 34 ff. Module "EU5E-SWD-4D4D-R" corrected ✓ 12/2017 155 ff. Dimmable LED ✓ – Chapter 7 „Electronic motor starter EMS-…-SWD-ADP“ ✓ replaced with "EMS-…-SWD, Electronic Motor Starter", MN034002ZU SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 14: Smartwire-Dt System Overview

    The latest version, which features all currently supported SWD modules, can be downloaded by using the integrated update function in SWD-Assist or directly from the Eaton Download Center: SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 15 SWD-Assist runs on the following operating systems: Windows Vista (32 Bit), Windows 7, Windows 8 and Windows 10. The SWD Assist software is available free of charge for down- load on the Eaton website at: They can be quickly located at http://www.eaton.eu ￫...

  • Page 16: Additional Documents Dealing With Smartwire-Dt

    Internet in PDF format at: http://www.eaton.eu/doc www.eaton.eu/DE/￫ Customer support ￫ Download cen- ter – Documentation Enter the document number ("05006002" or "120006", for exam- ple) or "SWD" into the Quick Search text field.

  • Page 17: Writing Conventions

    Warns of the possibility of hazardous situations that could result in serious injury or even death. DANGER  Warns of hazardous situations that result in serious injury or death. 0.5.3 Tips ￫ Indicates useful tips. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 18 0 About this manual 0.5 Writing conventions SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 19: Eu5C-Swd-Pf1-1, Eu5C-Swd-Pf2-1 Power Modules

    The looped back 24 V DC voltage is not electrically isolated from the 24 V DC supply voltage (AUX) of the module. There is voltage reversal and EMC pro- tection. Voltage dips are not buffered. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 20: Engineering

    "Mount the external device plug" sec- tion in manual MN05006002Z-EN (previously AWB2723- 1617en). The connection terminals are suitable for cables AWG24 to AWG16 and flex- ible conductors with a cross section of 0.5 to 1.5 mm SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 21: Diagnostics

    0.25 mm² to 1.5 mm², with the ferrule (minimum length 8 mm) • solid: 0.14 to 1.5 mm² ￫ Information on the cable protection is provided on Page 20 1.2.5 Diagnostics The device does not report a diagnosis SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 22: Eu5C-Swd-Pf2-1

    The 24 V DC contactor voltage that is looped back in is not electrically iso- lated from the 24 V DC supply voltage (AUX) of the module. There is voltage reversal and EMC protection. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 23: Engineering

    The connection terminals are suitable for cables AWG24 to AWG16 and flex- ible conductors with a cross section of 0.5 to 1.5 mm 24 V DC Figure 4: Terminal capacities • flexible, cross-section 0.25 mm² to 1.5 mm², with the ferrule (minimum length 8 mm) SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 24: Cable Protection

    Cable protection for cable AWG24 in accordance with UL 508 and CSA-22.2 no. 14: • Miniature circuit-breaker 24 V DC rated operational current 2 A; tripping characteristics Z or • Fuse 2 A 1.3.5 Diagnostics The device does not report a diagnosis SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 25: O Modules Eu5E-Swd

    2.2 Surface mounting a SmartWire-DT cable with external device plug b SmartWire-DT diagnostics LED c Input/output status displays (optional) d Input/output terminals e External supply (optional) Figure 5: Connections of a SmartWire-DT I/O module SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 26: Engineering

    "Parameter configuration" section for each individual module. For general information on the EtherCAT fieldbus system, please refer to ￫ Chapter 12 “Using SWD modules with the EtherCAT field bus”, page 247. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 27: Installation

    ▶ Route the cables separately from power leads or signal cables that carry differential voltages. ▶ Depending on the prevailing electromagnetic environment, one or both ends of the shielding should be earthed. ▶ Connect the shielding with the module’s 0 V supply. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 28: Commissioning

    After replacement of the modules and connection of the voltage the configu- ration button must be pressed. When this is done, the new module will be assigned an address. ACHTUNG The order of the SmartWire-DT units must not be altered. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 29: Device Status

    EU5E-SWD-4D4D-R ￫ Page 36 • EU5E-SWD-4D2R ￫ Page 42 • EU5E-SWD-X8D ￫ Page 46 Analog modules IP20 • EU5E-SWD-4AX ￫ Page 49 • EU5E-SWD-2A2A ￫ Page 54 • EU5E-SWD-4PT / EU5E-SWD-4PT-2 ￫ Page 59 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 30: Digital Module Eu5E-Swd-8Dx

    SmartWire-DT diagnostics LED c Status LEDs of the inputs d I0 – I7 (inputs) e 0-V connection Figure 8: Connections of the module EU5E-SWD-8DX 2.6.3 Engineering There are no specific engineering notes for this device model. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 31: Installation

    ￫ Chapter 12 “Using SWD modules with the EtherCAT field bus”, page 247, particularly ￫ Section , „Device options“, page 247.. 2.6.7 Programming The module has two input bytes at its disposal. 2.6.7.1 Input points Byte 0: SUBST PRSNT – DIAG – – – – SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 32 Description Status input I0 Status input I1 Status input I2 Status input I3 Status input I4 Status input I5 Status input I6 Status input I7 2.6.7.2 Diagnostics The module does not report a diagnosis. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 33: Digital Module Eu5E-Swd-4Dx

    0.5 A. The supply is short-circuit proof. On short circuit the SmartWire-DT diagnostics LED flashes and the diagnos- tic bit is set in the user program. When the short circuit is removed, the sup- ply voltage is automatically applied again. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 34: Installation

    Please note the general information for configuring parameters ￫ Chapter 12 “Using SWD modules with the EtherCAT field bus”, page 247, particularly ￫ Section , „Device options“, page 247.. 2.7.7 Programming The module has two input bytes at its disposal. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 35 Not used – Not used – 2.7.7.2 Diagnostics In case of diagnosis, the module reports the following fault cause (bit 4 in input byte 0 is set): Value Description 0x13 Short-circuit/overload at supply voltage SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 36: Digital Module Eu5E-Swd-4D4D

    The maximum current draw for each output is 0.5 A. The outputs are short- circuit proof. On short circuit the SmartWire-DT diagnostics LED flashes and the diagnostic bit is set in the user program. When the short circuit is removed, the supply voltage is automatically applied again. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 37: Installation

    ￫ Chapter 12 “Using SWD modules with the EtherCAT field bus”, page 247, particularly ￫ Section , „Device options“, page 247.. 2.8.7 Programming The module has two input bytes and one output byte at its disposal. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 38 NOP(C) present Byte 1: – – – – Designation Description Status input I0 Status input I1 Status input I2 Status input I3 Not used – Not used – Not used – Not used – SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 39 – Not used – 2.8.7.3 Diagnostics In case of diagnosis, the module reports the following fault cause (bit 4 in input byte 0 is set): Value Description 0x13 Short-circuit/overload on at least one output SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 40: Digital Module Eu5E-Swd-4D4D-R

    By configuring the module appropriately, the outputs' behavior can be changed in such a way that the output state will not be reset automatically in certain cases, such as a communication error on the field bus or the PLC stopping. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 41 (a few 100 ms). • Loading a new PLC configuration with modified parameters. 1 2 3 1 2 3 24 V 24 V DC Figure 15: Connecting inputs/outputs and power supply SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 42: Installation

    Field bus CANopen The module is parameterized through its associated parameter byte in the control configurator. For values other than the default, change these values as shown below. Structure of parameter byte 1: retentive behavior SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 43: Programming

    0: Output Q3 will be reset reserved 2.9.7 Programming The module has two input bytes and one output byte at its disposal. 2.9.7.1 Input points Byte 0: status SmartWire-DT SUBST PRSNT – DIAG – – – – SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 44 "1" will still be returned. 2.9.7.2 Outputs Byte 0: outputs The way the outputs are driven will depend on the selected configuration. Output configured as retentive: Driving will be based on a 2-bit combination for setting and resetting. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 45 No Change Output OFF 2.9.7.3 Diagnostics In case of diagnosis, the module reports the following fault cause (bit 4 in input byte 0 is set): Value Description 0x13 Short-circuit/overload on at least one output SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 46: Digital Module Eu5E-Swd-4D2R

    Connections of the modules EU5E-SWD-4D2R 2.10.3 Engineering Module EU5E-SWD-4D2R can be used for directly actuating AC or DC con- tactors with larger pull-in power. The relay outputs must be fuse-protected against overload and short-circuits. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 47: Installation

    ￫ Chapter 12 “Using SWD modules with the EtherCAT field bus”, page 247, particularly ￫ Section , „Device options“, page 247.. 2.10.7 Programming The module has two input bytes and one output byte at its disposal. 2.10.7.1 Input points Byte 0: SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 48 NOP(C) present Byte 1: – – – – Designation Description Status input I0 Status input I1 Status input I2 Status input I3 Not used – Not used – Not used – Not used – SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 49 Description Actuation output Q0 Actuation output Q1 Not used – Not used – Not used – Not used – Not used – Not used – 2.10.7.3 Diagnostics The module does not report a diagnosis. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 50: Digital Module Eu5E-Swd-X8D

    The maximum current draw for each output is 0.5 A. The outputs are short- circuit proof. On short circuit the SmartWire-DT diagnostics LED flashes and the diagnostic bit is set in the user program. When the short circuit is removed, the supply voltage is automatically applied again. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 51: Installation

    Please note the general information for configuring parameters ￫ Chapter 12 “Using SWD modules with the EtherCAT field bus”, page 247, particularly ￫ Section , „Device options“, page 247.. 2.11.7 Programming The module has one input byte and one output byte. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 52 Actuation output Q6 Actuation output Q7 2.11.7.3 Diagnostics In case of diagnosis, the module reports the following fault cause (bit 4 in input byte 0 is set): Value Description 0x13 Short-circuit/overload on at least one output SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 53: Analog Module Eu5E-Swd-4Ax

    The resolution is 12 Bit. ￫ All 0 V connections (I - ; x = 0, 1, 2, 3) are connected with each other and with the module’s 0 V supply. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 54: Installation

    This setting applies for all channels. The specified value is the refresh time to the SmartWire-DT coordinator. An averaging function, which smooths input signal fluctuations can be activated separately. 2.12.6 Fieldbus-specific characteristics Field bus CANopen SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 55 Bold values indicate the default settings. ￫ The CANopen field bus transmits data event-controlled when- ever the reading changes. Reducing the reading refresh rate, for example to 20 ms, can increase data traffic on the field bus. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 56: Programming

    Mean value 0 = off 1 = on reserved Bold values indicate the default settings. 2.12.7 Programming The module has an input byte for SmartWire-DT status and four input words for the analog inputs. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 57 In case of diagnosis, the module reports the following fault cause (bit 4 in input byte 0 is set): Value Description 0x13 Overload on at least one analog current input (I > 23 mA) SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 58: Analog Module Eu5E-Swd-2A2A

    The resolution is 12 Bit. The outputs are short-circuit proof. ￫ All 0 V connections (I - , Q - ; x = 0, 1) are connected with each other and with the module’s 0 V supply. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 59: Installation

    This setting applies to all analog inputs. The specified value is the refresh time for the SmartWire-DT network. An averaging function that smooths input signal fluctuations can be activated separately. 2.13.6 Fieldbus-specific characteristics Field bus CANopen SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 60 Bold values indicate the default settings. ￫ The CANopen field bus transmits data event-controlled when- ever the reading changes. Reducing the reading refresh rate, for example to 20 ms, can increase data traffic on the field bus. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 61: Programming

    1 = on reserved Bold values indicate the default settings. 2.13.7 Programming The module has an input byte for SmartWire-DT status, two words for the analog inputs and two output words for the analog outputs. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 62 0 is set): Value Description 0x13 Short-circuit/overload on at least one analog output 0x13 Overload on at least one analog current input (I > 23 mA) 0x14 No 24 V DC supply voltage connected SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 63: Analog Modules Eu5E-Swd-4Pt And Eu5E-Swd-4Pt-2

    If the sensor is connected as a two-wire sensor, terminals Ax-ax (x = 0, 1, 2, 3) must be connected to each other with a jumper. In the case of unused inputs, all three terminals need to be connected to each other with a jumper. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 64: Installation

    40 measurement cycles This setting applies to all analog inputs. The specified value is the refresh time for the SmartWire-DT network. An averaging function, which smooths input signal fluctuations, is associated with this setting. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 65: Fieldbus-Specific Characteristics

    = Binary value 2, 3 Reading refresh rate Bit 3 Bit 2 = 0.25 s = 1 s = 2.5 s = 10 s reserved reserved reserved reserved Bold values indicate the default settings. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 66 = not used = PT100 = PT1000 = NI1000 6, 7 Sensor selection Bit 7 Bit 6 Input 4 = not used = PT100 = PT1000 = NI1000 Bold values indicate the default settings. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 67: Programming

    – Not used – DIAG 0: no diagnostic alarm 1: Diagnostic alarm Not used – PRSNT 0: Module not available 1: Module available SUBST 0: Configured module present 1: universal module M22-SWD- NOP(C) present SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 68 Out-of-range low reading on at least one temperature input In this case, the reading at the affected input is at the value range limit. In the case of an open wire, the reading will be at the upper value range limit. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 69: Switching On Dil-Swd-32-001, Dil-Swd-32-002 Contactors

    The Smart- Wire Device Technology (SmartWire-DT) function elements listed in this manual can also be combined with equivalent Eaton basic devices that use the Eaton catalog number as part number. For a reference table, see the Appendix on Page 258.

  • Page 70: Surface Mounting

    ④. Feedback on the switching status of the contactor is goes into the field bus. In addition the status of the connected contactor can be acquired via the switch position indicator ②. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 71: Engineering

    Power consumptions of the contactor coils with a voltage of 24 V DC Contactor Pick-up power Pick-up current Sealing power Holding current with 24 V DC with 24 V DC [mA] [mA] DILA, DILM7 DILM9 – DILM15 DILM17 – DILM38 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 72: Dol Starter

    The DOL starter is assembled from a PKZM0 and a contactor DILM7 to DILM32. The SmartWire module for DILM is mounted on the contactor. The SmartWire-DT module for DILM is mounted on the contactor. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 73 1-0-A switch ⑨ in the device version DIL-SWD- 32-002. The switch positions are as follows: • 1 - Contactor ON • 0 - Contactor OFF • A - Switching command via SmartWire-DT SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 74: Reversing Starter

    The "Enable" ⑧ auxiliary contact is factory fitted with a link, ￫ Figure 30. For the electrical interlocking of the two contactors this link is removed and the auxiliary breaker (contacts 21-22) of the other contactor is linked in as a potential-free contact. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 75 Fig. 30. A manual or electrical ON or OFF command for the contactor can take place in addition with the aid of the 1-0-A switch ⑨ in the device version DIL-SWD- 32-002. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 76 Use of the 1-0-A switch for the electrical switching on or off of the contactor is ensured only when the SmartWire-DT module for DILM is supplied via the SmartWire-DT connecting cable. Figure 29: Circuit diagram of the reversing starter in combination with DILM12-XEV SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 77: Safety-Related Applications

    The SmartWire-DT system is not designed for the transfer of safety relevant signals. Using the following configuration the system SmartWire-DT can however be used for safety relevant switch-offs. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 78 3.3 Engineering DANGER  In safety-relevant applications the power supply providing power to the SmartWire-DT system must feature a PELV power supply unit (protective extra low voltage). Figure 31: Actuating circuit for safety relevant switch-off SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 79: Feedback Loop

    IEC/EC 60947-4-1. Using this contact the state of the main contacts can be reliably signalled. The mirror contact can be included into the feedback circuit of the safety relay so that the safety relay only gives a new enable signal when the contactor is open. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 80: Measures For Higher Safety Categories

    Category 3 control systems. The safety relay used must comply with Category 3 or higher (e.g. ESR5-NO-31-24VAC-DC) to attain this safety category. Figure 33: Actuating circuit for redundant switch-off SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 81: Application For En Iso13849-1 And En 62061

    PL d in accordance with EN ISO 13849-1 and SIL Cl2 in accordance with EN 62061. DANGER  The total assembly of the safety relevant controls must corre- spond to the required safety category. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 82: Applications In North America

    “Special Conditions for the use of motor-protective circuit-breakers and motor starters in North America”, VER1210+1280-928EN. This publication is available as a PDF file at the following Inter- net address: http://www.moeller.net/de/company/news/publications/index.jsp SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 83: Installation

    ▶ Set the setting slider on the SmartWire-DT module for the corresponding contactor: • Bottom position: DILA, DILM7, DILM9, DILM12, DILM15 • Top position: DILM17, DILM25, DILM32, DILM38 Position bottom Position top Figure 35: Adjustment of the adjusting slide on DIL-SWD-32-001 or DIL-SWD-32-002 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 84 Wire-DT connecting cable. SW D4- 8SF 2-5 + 15V SW D4 -8 SF 2- 5 SW D4 -8S F2 SW D4 -8S F2 + 15 V Figure 38: Connection of SmartWire-DT external device plug SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 85: Commissioning

    Device is operating fault-free. flashing (1 Hz) • addressing process in progress • after gateway power On • after actuation of the configuration button on the gateway • Module not in current configuration • invalid type SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 86: Parameterization

    The meaning depends on the auxiliary switch used. Not used – DIAG 0: no diagnostic alarm Not used – PRSNT 0: Module not available 1: Module available SUBST 0: Configured module present 1: Universal module M22-SWD-NOP(C) present 3.8.1.2 Outputs Byte 0: SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 87: Dil-Swd-32-002

    M = Manual 0: Automatic 1: Manual mode DIAG 0: no diagnostic alarm Not used – PRSNT 0: Module not available 1: Module available SUBST 0: Configured module present 1: Universal module M22-SWD-NOP(C) present SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 88 Designation Description Contactor actuation Not used – Not used – Not used – Not used – Not used – Not used – Not used – 3.8.2.3 Diagnostics The module does not report a diagnosis. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 89: Pke-Swd-32, Interface For Motor-Starter Combination With Pke Pke12/32

    Wire Device Technology (SmartWire-DT) function elements listed in this manual can also be combined with equivalent Eaton basic devices that use the Eaton catalog number as part number. For a reference table, see the Appendix on Page 258. The interoperability requirements for these SmartWire-DT modules are described in ￫...

  • Page 90: Surface Mounting

    The PKE-SWD-32 is connected via a slide catch ④ with the contact bridge of the contactor. This slide catch is used on the one hand for the electronic monitoring of the contactor state, and on the other as a mechanical switch position indication ② on the PKE-SWD-32. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 91: Engineering

    DOL starter (PKE and DILM) Reversing starter (PKE and 2 x DILM) The connected contactor is fed directly via the SmartWire-DT connection cable. The contactor coils have the following power consumptions with a voltage of 24 V DC: SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 92 Please take into consideration the total power consumption of your SmartWire-DT network and, if necessary, plan for an addi- tional feeder module EU5C-SWD-PF2-1. ￫ For data for the current requirement please refer to the table in the appendix on Page 254. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 93: Dol Starter

    PKE32-COM ⑪ makes the contact with the data interface of the PKE trip block. The data cable with the connector for the PKE-SWD-32 ⑩ is connected via the data interface ⑦ to the PKE-SWD- SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 94 A: switching command via SmartWire-DT ￫ Use of the 1-0-A switch for the electrical switching on or off of the contactor is ensured only when the PKE-SWD-32 is supplied via the SmartWire-DT connecting cable. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 95: Reversing Starter

    4.9.2, "Overload relay function (ZMR)", page 115). ACHTUNG The two SmartWire-DT modules PKE-SWD-32 and DIL-SWD-32 drive the contactors so that the terminals A1 and A2 need no further wiring, with the exception of the DILM12-XEV link. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 96 A manual or electrical ON or OFF command for the contactor can also be implemented by means of the 1-0-A switch ⑨. The switch positions are as follows: • 1: Contactor ON • 0: Contactor OFF • A: switching command via SmartWire-DT. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 97 Use of the 1-0-A switch for the electrical switching on or off of the contactor is ensured only when the PKE-SWD-32 is supplied via the SmartWire-DT connecting cable. Figure 42: Circuit diagram of the reversing starter in combination with DILM12-XEV SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 98 4 PKE-SWD-32, interface for motor-starter combination with PKE PKE12/32 4.3 Engineering Figure 43: Circuit diagram of the reversing starter SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 99: Safety-Related Applications

    (e.g. with cable duct, or hard PVC conduit). • The cables are provided as various non-metallic-sheathed cables. • The cables are located inside an electrical mounting area (e.g. switch cabinet). • The cables are protected by a ground connection. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 100 4 PKE-SWD-32, interface for motor-starter combination with PKE PKE12/32 4.3 Engineering 4.3.3.1 Safety-related disconnection of a single drive Figure 44: Actuating circuit for safety-related disconnection of a single drive SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 101 With this circuitry, controls can be assembled up to safety category 1 to EN 954-1 The safety relay must comply with Category 1 or higher (e.g. ESR5-NO-41- 24VAC-DC) in this example. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 102 4 PKE-SWD-32, interface for motor-starter combination with PKE PKE12/32 4.3 Engineering 4.3.3.2 Safety-related disconnection of drive groups Figure 46: Actuating circuit for safety-related disconnection of drive groups SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 103: Feedback Loop

    IEC/EC 60947-4-1. Using this contact the state of the main contacts can be reliably signalled. The mirror contact can be included into the feedback circuit of the safety relay so that the safety relay only gives a new enable signal when the contactor is open. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 104: Measures For Higher Safety Categories

    Category 3 control systems. The safety relay used must comply with Category 3 or higher (e.g. ESR5-NO-41-24VAC-DC) to attain this safety category. Main circuit for redundant disconnection of a single drive Figure 48: Actuating circuit for redundant disconnection of a single drive SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 105 I> I> I> I> I> I> I> I> I> -Q11 -Q12 -Q13 -Q16 W PE W PE W PE W PE W PE W PE Figure 49: Main circuit for redundant disconnection of a single drive SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 106 4 PKE-SWD-32, interface for motor-starter combination with PKE PKE12/32 4.3 Engineering 4.3.5.1 Redundant disconnection of drive groups Figure 50: Actuating circuit for redundant disconnection of drive groups SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 107: Application For En Iso 13849-1 And En 62061

    PL d in accordance with EN ISO 13849-1 and SIL Cl2 in accordance with EN 62061. DANGER  The total assembly of the safety relevant controls must corre- spond to the required safety category. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 108: Applications In North America

    North American market must be fitted additionally with a mechanical and electrical interlock. The electrical locking is realized via the connection "Enable" ⑧ auxiliary contact. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 109: Installation

    PKE32-COM. 4.4.1 Mounting PKE32-COM ▶ Remove the empty module on the PKE basic device. ▶ Connect the PKE32-COM on the PKE basic device. ▶ Fit the “Advanced” part no. of PKE trip block (PKE-XTUA-…). SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 110: Mounting Pke-Swd-32

    Position bottom: DILM7, DILM9, DILM12, DILM15 (state of delivery) • Position top: DILM17, DILM25 and DILM32 ▶ Set the PKE-SWD-32 for the appropriate contactor. ▶ Interlock the PKE-SWD-32. ▶ Remove the cover of the communication interface. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 111: Commissioning

    (actuation of the configuration pushbutton on the gateway) during commissioning. During the addressing process the Smart- Wire-DT diagnostics LED flashes. Once the addressing process is com- pleted, the LED indicates a green continuous light. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 112: Exchange Of Modules

    • Communication to PKE is interrupted 4.8 Parameterization Depending on the coordinator being used, the module's parameters will need to be configured in the programming system or in the SWD-Assist plan- ning and commissioning program. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 113: Programming

    1: Module signals diagnostics PRSNT 0: Module not available 1: Module available SUBST 0: Configured module present 1: Universal module M22-SWD-NOP(C) present Byte 1: Set value I , trip reasons, acknowledge signal ACKR TRIPR TRIPR TRIPR SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 114 Control option part no. ￫ Section 4.9.1.8, "Type of trip block (TYPE)", page 114 3 - 5 CLASS Set time lag ￫ Section 4.9.1.9, "Time delay setting (CLASS)", page 114 Not used Not used SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 115 (input byte 1, bit 0, ..., 3). The value of this bit field indicates the set absolute current value of the overload release that varies according to the PKE trip block selected. Bit field I has the following meaning for the different PKE trip blocks: SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 116 PKE are reclosed and a current flow is sensed through the PKE trip block. The trip reason 0x5 “Overload with activated ZMR function” is reset if the thermal motor image (TH) is below 100 %. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 117 100 % of the thermal motor image. In the event of a phase unbalance and trip caused by an overload, the value of the thermal motor image is raised from 100 % to 110 %. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 118 The setting points of the time lag class dial are assigned to the following values of the CLASS bit field. Table 14: Bit field Time delay setting (CLASS) SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 119: Overload Relay Function (Zmr)

    The reclosing readiness of the contactor can be selected by the two manual and automatic operating modes of the ZMR function. ￫ The ZMR function can only be used in position A of the 1-0-A switch. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 120 The "manual" ZMR operating mode is activated by sending the value "0" in bit field ZMR M/A (output byte 0, Bit 3). SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 121 Acknowledgement of manual ZMR operating mode by “Contactor OFF” command a Thermal motor image b Switch command for contactor c Switch status Contactor d ACKR bit field status e Trip indication: Overload with activated ZMR function SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 122 Switch status Contactor e ACKR bit field status f Trip indication: Overload with tripped ZMR function ACHTUNG The ZMR function cannot be deactivated until the thermal motor image falls below the 100 % mark. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 123 "automatic" ZMR operating mode active. 110% 100% Figure 54: "Automatic" ZMR operating mode a Thermal motor model b Switch command for contactor c Switch status Contactor d Trip reason: Overload with activated ZMR function SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 124: Data Profiles

    0x2091 Profile 2 (default) 0x2093 Profile 3 0x2094 ￫ Data bytes that are not transferred cyclically in certain profiles can still be read as acyclical data objects (￫ Section 4.9.4, "Acyclic data", page 121). SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 125: Acyclic Data

    ￫ Section 4.9.1.6, "Motor current [%] (I-REL)", page Object 2 [Index 2]: Byte 0: Data byte Data bit Designation Description Notes 0 - 7 Thermal motor ￫ Section image [%] 4.9.1.7, "Thermal motor image [TH]", page 113 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 126 ￫ Section 4.9.1.9, "Time delay setting (CLASS)", page 114 Not used – – Not used – – ￫ Further information on the subject of "acyclical data transfer" is provided in the manual MN05013002Z-EN (previous designation AWB2723-1612en). SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 127: Connection Pke-Swd For Motor-Protective Circuit-Breaker Pke12/32/65

    SmartWire-DT system listed in this manual can also be combined with equivalent Eaton basic devices that use the Eaton catalog number as part number. For a reference table, see the appendix on Page 258. The interoperability requirements for these SmartWire-DT modules are described in ￫...

  • Page 128: Surface Mounting

    PKE basic devices must be of type XTUA or PKE-XTUWA. For each PKE- SWD one motor-protective circuit-breaker PKE with PKE trip block can be connected. The following trip blocks of the type “Advanced” can be combined with the two PKE basic devices PKE12, PKE32 and PKE65. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 129 Please take into consideration the total power consumption of your Smart- Wire-DT network and, if necessary, plan for an additional feeder module EU5C-SWD-PF2-1. ￫ For data for the current requirement please refer to the table in the appendix on Page 253. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 130: Installation

    ▶ Wire the main circuits of the PKE device. ▶ Remove the empty module on the PKE basic device. ▶ Connect the PKE-SWD on the PKE basic device. ▶ Fit the “Advanced” part no. of PKE trip block (PKE-XTUA-…). SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 131: Commissioning

    (actuation of the configuration pushbutton on the gateway) during commissioning. During the addressing process the Smart- Wire-DT diagnostics LED flashes. Once the addressing process is com- pleted, the LED indicates a green continuous light. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 132: Exchange Of Modules

    SWD-Assist plan- ning and commissioning program. 5.9 Fieldbus-specific characteristics Field bus Ethercat Please note the general information for configuring parameters ￫ Section 12, „Using SWD modules with the EtherCAT field bus“, page 247. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 133: Programming

    Data bit Designation Description Notes Set value I ￫ Section 5.10.1.4, „Set value (Ir)“, page 132 TRIPR = Trip Reason ￫ Section 5.10.1.5, „Differential trip Trip reason indication (TRIPR)“, page 133 Not used – – SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 134 Control option part no. ￫ Section 5.10.1.8, „Type of trip block (TYPE)“, page 134 3 - 5 CLASS Set time lag ￫ Section 5.10.1.9, „Time delay setting (CLASS)“, page 135 Not used Not used SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 135 In the event of a diagnosis the module reports the following error causes (input byte 0, bit 4 is set): Value Description Remedy 0x03 No communication between PKE-SWD and Check whether the PKE trip block used is of part PKE trip block no. PKE-XTU(W)A. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 136 2.40 7.00 19.00 37.70 0.77 2.60 7.70 20.50 40.90 0.83 2.80 8.30 22.00 44.40 0.90 3.00 9.00 24.00 48.10 1.00 3.30 10.00 27.00 53.30 1.10 3.70 11.00 29.00 58.60 1.20 4.00 12.00 32.00 65.00 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 137 (0xFF). The transferred relative value is calculated from the value of the high- est phase current measured in relation to the set current value of the over- load release. The accuracy of the relative current indication depends on the SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 138 The type of PKE trip block is mapped via the TYPE bit field (input byte 4, Bit 0 - 2). The values of this bit field are assigned to the following PKE trip blocks: SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 139 = 0.85 × 1A = 0.85 A). The maximum duration of the tripping process from the time the PKE-SWD receives the trip signal to the actual time of tripping of the PKE basic device is 700 ms. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 140: Data Profiles

    “ID”. Meanwhile, the "Index" parameter specifies the address of the actual object. The first object is assigned num- ber 1, the second 2 etc. For the PKE-SWD, object 1 supplies current value “I- REL”. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 141 5.10.1.6, „Relative current value (I-REL)“, page 133 Object 2 [Index 2]: Byte 0: Data byte Data bit Designation Description Notes 0 - 7 Thermal motor ￫ Section image [%] 5.10.1.7, „Thermal motor image [TH]“, page 134 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 142 ￫ Section 5.10.1.9, „Time delay setting (CLASS)“, page 135 Not used – – Not used – – ￫ Further information on the subject of "acyclical data transfer" is provided in the manual MN05013002Z-EN (previous designation AWB2723-1612en). SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 143: Pke-Swd-Cp, Connection For Circuit-Breaker Pke

    SmartWire-DT system listed in this manual can also be combined with equivalent Eaton basic devices that use the Eaton catalog number as part number.For a reference table, see the Appendix Page 253.

  • Page 144: Surface Mounting

    ③. This must be operated before the PKE-SWD-CP is removed. When installing the PKE-SWD-CP, the PKE basic device must not be fitted with a PKE trip block. PKE-SWD-CP and PKE trip block communicate through the data interface ④. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 145: Engineering

    Take the total power consumption of your SmartWire-DT system into account. If necessary, add an additional EU5C-SWD-PF2-1 power feeder module to your configuration. ￫ For data for the current consumption please refer to the table ￫ Chapter 13 “Appendix”, page 253 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 146: Installation

    PKE trip block installed on it. ▶ Wire the main circuits of the PKE device. ▶ Remove the empty module on the PKE basic device. ▶ Connect the PKE-SWD-CP on the PKE basic device. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 147: Commissioning

    The SmartWire-DT diagnostics LED will flash while addresses are being assigned. Once all addresses have been assigned, the diagnostics LED will light up with a solid green light. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 148: Exchange Of Modules

    SWD-Assist plan- ning and commissioning program. 6.9 Fieldbus-specific characteristics Field bus Ethercat Please note the general information for configuring parameters ￫ Chapter 12 “Using SWD modules with the EtherCAT field bus”, page 247. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 149: Programming

    TRIPR Data bit Designation Description Notes Set value I ￫ Section 6.10.1.4, „Set value (Ir)“, page 148 TRIPR = Trip Reason ￫ Section 6.10.1.5, „Differential trip Trip reason indication (TRIPR)“, page 149 Not used SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 150 Not used Byte 5: I-REL-L1 I-REL-L1 I-REL-L1 I-REL-L1 I-REL-L1 I-REL-L1 I-REL-L1 I-REL-L1 Data bit Designation Description Notes 0 - 2 I-REL-L1 Relative phase current L1 ￫ Section 6.10.1.6, „Relative current value (I-REL)“, page 149 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 151 PKE-XTU(W)ACP-36 PKE-XTUACP-65 single- 15 A phase two-phase three-phase 6.10.1.3 Diagnostics In the event of a diagnosis the module reports the following error causes (input byte 0, bit 4 is set): SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 152 39.30 21.70 21.70 41.60 23.00 23.00 44.00 24.30 24.30 46.30 25.70 25.70 48.30 27.00 27.00 51.00 28.30 28.30 53.30 29.70 29.70 55.60 31.00 31.00 58.00 32.70 32.70 60.30 34.30 34.30 62.60 36.00 36.00 65.00 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 153 PKE trip block. The maximum measuring accuracy of the transferred relative current value is 5 %. This value will be achieved if the phase current being measured exceeds the minimum trip block currents specified below: SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 154 The type of PKE trip block is mapped via the TYPE bit field (input byte 4, Bit 0 - 2). The values of this bit field are assigned to the following PKE trip blocks: SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 155 The I > bit field can assume the following values: Table 30: Bit array I > Field Value Short-circuit release factor I > Test position Not defined Not defined Not defined Not defined SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 156: Data Profiles

    0x2093 Profile 3 0x2094 Profile 4 0x2095 ￫ Data bytes that are not transferred cyclically in certain profiles can still be read as acyclical data objects (￫ Section 6.10.3, „Acyclic data PKE-SWD-CP“, page 153). SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 157: Acyclic Data Pke-Swd-Cp

    Control option part ￫ Section 6.10.1.8, „Type of trip block (TYPE)“, page 3 - 5 I > Factor for short- ￫ Section circuit current 6.10.1.9, „Short-circuit release (I >) factor“, page Not used – – SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 158 6.10.1.6, „Relative current value (I-REL)“, page 149 ￫ For more information on the subject of acyclic data transfers, consult the manuals • SmartWire-DT gateway EU5C-SWD-DP, MN120001Z-DE, • SmartWire-DT gateway EU5C-SWD-CAN, MN120002Z-DE, • SmartWire-DT gateway EU5C-SWD-EIP-MODTCP, MN120003Z-DE. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 159: Pilot Devices M22-Swd

    These elements are available with a front mounting configuration. 7.2 M22-SWD front mount M22-SWD front function elements are used in connection with the M22-A adapter and M22 front elements for installation in consoles or control box doors. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 160: Surface Mounting

    M22-A adapter. A possible application is, for example, conventional switching via an M22-K... contact element and the reporting of this pro- cess to the PLC via the M22-SWD-K11 function element. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 161 M22-SWD-K22 function elements, is used for 4-position contact polling (e.g. joystick M22S-WJ4) instead of the adapter M22-A4. All combination options for M22 front elements with SmartWire-DT function elements for front mount are listed in the following table. Figure 58: SmartWire-DT:Function elements SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 162 - viewed from the rear while equip- ping the adapter) Marking on adapter M22-SWD-K11 M22-SWD-LED M22-SWD-K11LED M22-SWD-K22 M22-SWD-K22LED 1) X = occupied by SWD element 2) O = optional for an additional M22-K10/K01 element SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 163 Due to electrostatic reasons, the function element must first be mounted on the front element before the external device plug is used to establish a con- nection to the SmartWire-DT system. SWD4-…LF… SWD4-8SF2-5 M22-SWD-R M22-R-SWD Figure 59: M22-SWD-R front mount SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 164: Installation

    Figure 61: Connection to the adapter The SWD ribbon cable is to connected to the SmartWire-DT network. The external device plug SWD4-8SF2-5 is used for bonding with the M22- SWD function element. This completes installation. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 165: Commissioning

    After replacement of the modules and connection of the voltage the configu- ration button must be pressed. When this is done, the new module will be assigned an address. ACHTUNG The order of the SmartWire-DT units must not be altered. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 166: Device Status

    The various function elements have specific input/output information that is processed in the programming system. The meaning and scope are described in the following. 7.2.9.1 M22-SWD-K11 The function element has one input byte at its disposal. Input points Byte 0: SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 167 Value Description 0x10 The contact is in the middle position for longer than four seconds. 0x11 Contact short-circuit 7.2.9.2 M22-SWD-K22 The function element has one input byte at its disposal. Input points Byte 0: SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 168 The contact is in the middle position for longer than four seconds. 0x11 Contact short-circuit 7.2.9.3 M22-SWD-LED-(W/B/G/R) The function element has one input byte and one output byte at its disposal Input points Byte 0: SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 169 Q0 Table 35: Brightness setting DIM2 DIM1 DIM0 Full brightness First dimming setting Eighth dimming setting Diagnostics The module does not report a diagnosis. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 170 (as in profile 4). The color information will be transmitted at runtime with cyclical services. All profiles allow for the LED to flash. Moreover, profiles 2 to 5 allow dim- ming. Profile Number of input bytes Number of output bytes SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 171 (200, 0, 0) Green (0, 200, 0) Yellow (100, 100, 0) Blue (0, 0, 200) Green (0, 200, 0) 50/50 % 1 Hz White (70, 70, 70) (200, 0, 0) 50/50 % 1 Hz SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 172 By changing the content of bits 1 to 2, the mark-to-space ratio for LED flash- ing can be defined. If both bits have a state of "0", there will be no flashing even if a flashing frequency has been set. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 173 25 / 75 75 / 25 Byte 1: Color selection with index in the color table. For more information, please refer to the color table ￫ Section “13.4.2 Color table profile 2...5”, page 257. Index SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 174 By changing the content of bits 1 to 2, the mark-to-space ratio for LED flash- ing can be defined. If both bits have a state of "0", there will be no flashing even if a flashing frequency has been set. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 175 The color is selected with R, G, B color components in the color space. The red and blue components can be defined at any of 32 levels, the green com- ponent at any of 64. Red component Green component Blue component SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 176 By changing the content of bits 1 to 2, the mark-to-space ratio for LED flash- ing can be defined. If both bits have a state of "0", there will be no flashing even if a flashing frequency has been set. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 177 Color selection with green component of 0 to 255 in RGB color space. Green color component Byte 3: Color selection with blue component of 0 to 255 in RGB color space. Blue color component SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 178 By changing the content of bits 1 to 2, the mark-to-space ratio for LED flash- ing can be defined. If both bits have a state of "0", there will be no flashing even if a flashing frequency has been set. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 179 Color selection with blue component of 0 to 255 in RGB color space. Blue color component Diagnostics In the event of a diagnosis the module reports the following error causes (0 is set for bit 4 in the input byte): SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 180 Dimming the mixed color will reduce an RGB color compo- nent to such an extent that it will assume a value of 1. In this case, it will no longer be possible to reproduce the mixed color correctly. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 181 0: Configured module present 1: Universal module M22-SWD-NOP(C) present Outputs Byte 0: DIM2 DIM1 DIM0 – – – – Designation Description Activation of the LED Not used – Not used – Not used – Not used – SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 182 0x11 Contact short-circuit 7.2.9.6 M22-SWD-K22LED-(W/B/G/R) The function element has one input byte and one output byte at its disposal. Input points Byte 0: SUBST PRSNT – DIAG numer- numer- ical ical convert convert SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 183 DIM1 DIM0 Full brightness First dimming setting Eighth dimming setting Diagnostics In the event of a diagnosis the module reports the following error causes (0 is set for bit 4 in the input byte): SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 184 (0 – 100.0%) or an absolute value (0 – 1023). Outputs none Diagnostics In the event of a diagnosis the module reports the following error causes (0 is set for bit 4 in the input byte): SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 185 Bold values indicate the default settings. ￫ The CANopen field bus transmits data event-controlled when- ever the reading changes. Reducing the reading refresh rate, for example to 50 ms, can increase data traffic on the field bus. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 186 1. This makes it possible to detect instances in which the sent reset value is not applied successfully. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 187 The counter value is reset to the value defined in bytes 1 and 2 with a rising edge Not used – Not used – Not used – Not used – Not used – Not used – Byte 1 and 2: SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 188 0, bit 1 or with the confirmation button (parameter byte 0, bit 6 must be set to 1), ￫ table 51. The reset value can be changed by changing the value of bytes 5 and 6 in parameter byte 0. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 189 (available from device version 02). Reset value (in profile 2 only) The reset value applied when a reset is carried out (with the confirmation button (if enabled) or with the PLC). SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 190: Fieldbus-Specific Characteristics

    1 = The count will increase when the encoder is turned counter- clockwise Quick scrolling 0 = Off 1 = On 2, 3 Reading refresh rate Bit 2 Bit 3 20 ms 100 ms 200 ms 500 ms Bold values indicate the default settings. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 191 1 = The count will increase when the encoder is turned counter- clockwise Quick scrolling 0 = Off 1 = On 2, 3 Reading refresh rate Bit 2 Bit 3 20 ms 100 ms 200 ms 500 ms Bold values indicate the default settings. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 192 0 = "Pushbutton fault" (0x2E) will be signaled 1 = "Pushbutton fault" (0x2E) will not be signaled Bold values indicate the default settings. For additional information, please refer to "Fieldbus-specific characteristics" in the "Parameter configuration" section for each individual module. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 193: M22-Swd Base Fixing

    SmartWire-DT round cable SWD4 50LR8-24. The round cable can be connected directly by means of VM20 (metric cable gland) or plugged in. 8 pole enclosure bushings as plug/socket versions are used for the plug-in version. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 194 Connection to the round cable in this case is via 8 pole plugs/sockets. Housing bushing sockets SWD Element Socket, straight, 8-pole SWD4-SF8-67 Plug, flat, 8-pole SWD4-SM8-67 Socket, angled at 90°, 8 pole SWD4-SF8-67W Plug, angled at 90°, 8 pole SWD4-SM8-67W SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 195 You can also obtain information about terminating resistors and on the use of the SWD link via the software program SWD- Assist. http://www.eaton.eu/software One SmartWire-DT function element is used per slot. Correspondingly more efficient function elements are used for the combined function of a luminous command device or for the realization of a multi-step switch.
  • Page 196 M22(S)-WLKV-3 M22-SWD-K22LEDC The SmartWire-DT function element always occupies the middle slot. If required, standard M22-KC10/KC01 contact elements can also be plugged into the free slots. The following Table 53 shows what possibilities there are. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 197 You will find information on the current consumption in the appendix on Page 253. For questions about current consumption the software program SWD-Assist also supports you in doing this by automatically per- forming these calculations. http://www.eaton.eu/software SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 198: Installation

    Bus termination resistor ▶ Equip the slots with the M22-SWD…C… function elements. Ensure that the mounting position is correct (status LED must be at the top). Unused slots must be equipped with the bridge M22-SWD-SEL8 10. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 199: Commissioning

    After replacement of the modules and connection of the voltage the configu- ration button must be pressed. When this is done, the new module will be assigned an address. ACHTUNG The order of the SmartWire-DT units must not be altered. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 200: Device Status

    The various function elements have specific input/output information that is processed in the programming system. The meaning and scope are described in the following. 7.3.9.1 M22-SWD-KC11 The function element has one input byte at its disposal. Input points Byte 0: SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 201 Value Description 0x10 The contact is in the middle position for longer than four seconds. 0x11 Contact short-circuit 7.3.9.2 M22-SWD-KC22 The function element has one input byte at its disposal. Input points Byte 0: SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 202 The contact is in the middle position for longer than four seconds. 0x11 Contact short-circuit 7.3.9.3 M22-SWD-LEDC-(W/B/G/R) The function element has one input byte and one output byte at its disposal. Input points Byte 0: SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 203 Q0 Table 55: Brightness setting DIM2 DIM1 DIM0 Full brightness First dimming setting Eighth dimming setting Diagnostics The module does not report a diagnosis. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 204 DIM0 – – – – Designation Description Activation of the LED Not used – Not used – Not used – Not used – DIM0 Dimming setting adjustments (device version 02 and higher) DIM1 DIM2 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 205 0: contact 1 not actuated 1: contact 1 actuated NC2 = Normally Closed 0: contact 2 actuated 1: contact 2 not actuated NO2 = Normally Open 0: contact 2 not actuated 1: contact 2 actuated SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 206 In the event of a diagnosis the module reports the following error causes (0 is set for bit 4 in the input byte): Value Description 0x10 The contact is in the middle position for longer than four seconds. 0x11 Contact short-circuit SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 207: Sl4-Swd And Sl7-Swd Base Modules For Signal Towers

    ￫ The interoperability requirements for these SmartWire-DT mod- ules are described in ￫ Section 13.6, „SWD module interoper- ability requirements“, page 259. 8.2 Surface mounting Figure 69: Lateral view of base modules SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 208 X2 (OUT) SmartWire-DT socket for output with blade terminal c External 24 VDC auxiliary power (optional) d SmartWire Module LED e Jumper for selecting external/internal power supply 24V- f Jumper for selecting external/internal power supply 24V+ SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 209: Engineering

    For more information, please refer to the man- ual "SmartWire-DT The system", MN05006002Z. ￫ For data regarding the SmartWire-DT modules' current con- sumption, please refer to the tables in the appendix on pages 253 and 254. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 210: Installation

    ▶ If necessary, connect an external auxiliary power, ￫ Section 8.4.2, „Connecting the external supply voltage“, page 208. ▶ Connect the SmartWire DT￫ Section 8.4.3, „Connect SmartWire-DT“, page 208. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 211 For detailed instructions on how to connect the SWD4-8MF2 SmartWire-DT external device plug for the 8-pin SmartWire-DT ribbon cable, please refer to the "Mount the SWD4-8MF2 blade terminal" chapter in the "SmartWire-DT The system", MN05006002Z manual. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 212: Connecting The External Supply Voltage

    The external supply voltage is applied. 8.4.3 Connect SmartWire-DT SWD stations may be destroyed if they are refitted in the SWD  line when the power supply is on. Switch off the power supply beforehand! SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 213: Terminal Capacities

    External auxiliary power, 24 V DC Figure Version Terminal capacity Flexible with ferrule 0.25 - 1.5 mm² (Minimum length 8 mm) ≧ 8 mm (≧ 0.31” solid 0.25 to 1.5 mm² (AWG 24 - 16) SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 214: Commissioning

    15 V supply voltage 8.6 Parameterization Depending on the coordinator being used, the module's parameters will need to be configured in the programming system or in the SWD-Assist plan- ning and commissioning program. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 215: Fieldbus-Specific Characteristics

    8.7.2 Outputs Byte 0: – – – Designation Description Turns on light module Q0 Turns on light module Q1 Turns on light module Q2 Turns on light module Q3 Turns on light module Q4 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 216: Diagnostics

    8 SL4-SWD and SL7-SWD base modules for signal towers 8.7 Programming 8.7.3 Diagnostics In case of diagnosis the module reports the following error cause (bit 4 in input byte 0 is set): Value Description 0x13 Short-circuit/overload on at least one output SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 217: Interface Module Mcb-Hk-Swd For Circuit-Breakers And Residual Current Circuit-Breakers

    The connection to the SmartWire-DT ribbon cable is implemented via the SWD device plug SWD4-8SF2-5. The connection can be established either to the top or bottom of the interface module. The unused connector must be covered with the included cap. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 218 Please take into consideration the total power consumption of your SmartWire- network and, if necessary, plan for an addi- tional feeder module EU5C-SWD-PF2-1. The software programme SWD-Assist also supports you in doing this by automatically performing these calculations. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 219: Installation

    Due to EMC reasons, the SmartWire-DT socket strip that remains unused must be covered with included accessory SWD4-…. Failure to do so may result in communication problems and in SmartWire-DT modules being damaged and ruined. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 220: Commissioning

    On • after actuation of the configuration button on the gateway • Module not in current configuration • invalid type flashing (3 Hz) Device reports a diagnostics. (￫ Section 9.8.2, "Diagnostics", page 217) SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 221: Programming

    4 in the input byte): Value Description 0x19 Check the connection between the SmartWire-DT auxiliary contact and the circuit-breakers and switch the circuit-breakers on and off. If the fault continues to be present, replace the SmartWire-DT auxiliary contact. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 222 9 Interface module MCB-HK-SWD for circuit-breakers and residual current circuit-breakers 9.8 Programming SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 223: Smartwire-Dt Universal Module M22-Swd-Nop And M22

    ▶ If a universal module is later replaced with the originally configured SmartWire-DT module, add this module to the SmartWire-DT network by pressing the “Config.” button on the gateway. 10.2 Surface mounting The universal modules can be both front- and base-fixed. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 224: Front Mounting

    Can be mounted directly on top-hat rail. • Telescopic clip for height compensation, for example to the motor-starter combinations. 10.2.2 Base mounting Base-fixing universal modules M22-SWD are used as placeholders in combi- nation with surface mounting enclosures M22-I…. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 225: Engineering

    Bit 7 (SUBST) in the first input byte is set if a universal module is fitted in place of the software-configured module. The program flow must be controlled according to this information. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 226: Installation

    SWD4-10LF8-24S SW D4 -8 SF 2- 5 + 15V SW D4 -8 SF 2 SW D4 -8 SF 2 + 15 V Figure 83: Connection of the universal module to the SWD ribbon cable SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 227: Base Mounting

    LED indicates a green continuous light. 10.5.1 Exchange of modules ATTENTION Switch off the entire SmartWire-DT system before replacing SmartWire-DT universal modules. ATTENTION The order of the SmartWire-DT units must not be altered. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 228: Device Status

    Bit 7 (SUBST) in the first input byte is set to indicate that a universal module is fitted in place of the software-configured module.All process data of the configured module is zero. Figure 85: M22-SWD-NOP, M22-SWD-NOPC SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 229 DIAG Designation Description DIAG 0: no diagnostic alarm Not used – PRSNT 0: Module not available 1: Module available SUBST 1: Universal module M22-SWD-NOP(C) present 10.6.0.1 Diagnostics The module does not report a diagnosis. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 230 10 SmartWire-DT universal module M22-SWD-NOP and M22-SWD-NOP-C 10.6 Programming SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 231: Interface For Nzm Compact Circuit-Breakers

    The interoperability requirements for these SmartWire-DT modules are described in ￫ Section 13.6, "SWD module interoperability requirements", page 259. 11.2 Surface mounting LT306.230.3 Figure 86: Fitting of NZM with NZM-XSWD-704 a SmartWire-DT connection b Data cable NZM with NZM-XSWD-704 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 232 ￫ For detailed instructions on how to connect the SmartWire-DT external device plug (SWD4-8SF2-5) to the 8-pin SmartWire-DT ribbon cable, refer to the "Installing SWD4-8SF2-5 external device plugs" section in manual MN05006002Z-EN (previously AWB2723-1617en). SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 233: Indication And Connection Elements

    The voltage state of the outputs is indicated: Q0 Led Q1 Led Attribute ID 11.2.2 Porting The module does not require an auxiliary power supply, it is supplied com- pletely via the SmartWire-DT connecting cable. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 234: Input Points

    If the counter input is not required, terminals S0+ and S0- must be provided with a wire bridge. This suppresses a starting pulse when the power supply is switched on. ￫ The 1.5-kΩ-resistor is permanently integrated in the NZM- XSWD-704 device. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 235: Control Outputs Q0 And Q1

    The outputs must only be used to actuate the remote operator. The remote operator can only be used for normal operational on/ off switching. Any disconnection in the event of a fault must always be implemented with an undervoltage release. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 236: Engineering

    The maximum number of NZM-XSWD-704 modules on a SWD line depends on the field bus gateway used and the data profile selected Data for engineering PROFIBUS-DP CANopen Maximum number of modules at the SWD line Max. input data [Byte] Max. output data [Byte] SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 237: Safety-Related Applications

    After replacement of the modules and connection of the voltage the configu- ration button must be pressed. When this is done, the new module will be assigned an address. ACHTUNG The order of the SmartWire-DT units must not be altered. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 238: Parameterization

    From byte 1, the data structure of profile 1 and 2 complies with the LVSG (Low Voltage Switchgear) profile of the PNO (PROFIBUS User Organization). Table 63: Overview of the data profiles of the NZM-XSWD-704 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 239 In programming systems with a controller configurator without automatic profile selection for SDO parameterization the corresponding SDO object 2102subx is inserted in the SDO object list and its content transferred when data profile 1, 3 or 4 is used. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 240 1) The last cause of tripping registered is always indicated. The circuit-breaker is reset by switching it on, or by switching the power supply off/on. It may take up to 30 s before the trip reason is displayed. After a trip, the last current values measured are displayed (rms values). SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 241 Byte Dec. Description Remark value = 0.5 x I Set value for I = 0.55 x I = 0.6 x I = 0.65 x I = 0.7 x I = 0.75 x I SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 242 Set value for I = 2.5 x I = 3 x I = 3.5 x I = 4 x I = 5 x I = 6 x I = 7 x I = 8 x I SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 243 = 14 x I • NZMX-VEF…-NA, -VE…-NA • NZM2-ME…-NA Set value for t = 10 = 12 = 14 = 17 = 20 • NZM3-4-VE630 Set value for t = 10 = 14 = infinite SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 244 Set value for I = 2.5 x I = 3 x I = 3.5 x I = 4 x I = 4.5 x I = 5 x I = 5.5 x I = 6 x I SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 245 = 0.7 x I = 0.8 x I = 0.9 x I = 1.0 x I Set value for t [ms] = 20 = 60 = 100 = 200 = 300 = 500 = 750 = 1000 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 246 An additional byte is provided for resetting the energy value. Byte Description Remark Do not change status – Switch off Switch command Switch on Switch command Do not change status – Not used – Reset power meter to zero Power meter SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 247 Measures for using the remote operator For devices belonging to device versions up to 03: SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 248 If you are using the remote operator, upgrade the NZM-XSWD-704 to device version 04. This upgrade is free. Then program the logic described in the fol- lowing section for devices belonging to device version 04 or higher. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 249: Decoding Cb Type And Cb Identification

    • Exchange the module. 0x16 Power meters invalid • Reset counter value via output command A memory error has occurred in the and observe whether the fault is rectified. NZM-XSWD-704. • Replace module as memory is faulty. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 250: Acyclic Data

    2 and that the actual parameters and circuit-breaker is read acyclically as required. This strategy reduces the bus load. ￫ Further information on the subject of "acyclical data transfer" is provided in the manual SmartWire-DT Gateway EU5C-SWD-DP (MN05013002Z), please visit www.eaton.eu/doc. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 251: Using Swd Modules With The Ethercat Field Bus

    FALSE (0): It is not permitted for the device to be replaced with module a universal module (default setting). TRUE( 1): It is permitted for the device to be replaced with a universal module. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 252 If you wanted data communications on the SmartWire-DT network to con- tinue even when the module is not present, bit 1 would need to be set to 0. The option byte's new value would then be 0x81. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 253 Programming system TwinCAT If the modules have 1, 2 or 4 bytes including the length bytes, they are shown in the overview as a hexadecimal value, otherwise in ascending order. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 254 For the two examples above, this means: • EU5E-SWD-2A2A module: • Length byte: 2 • Parameter byte 1: 50 • EU5E-SWD-4PT module: • Length byte: 3 • Parameter byte 1: 00 • Parameter byte 2: 00 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 255 12 Using SWD modules with the EtherCAT field bus Figure 90: Dialog window in which parameter values are entered or changed SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 256 12 Using SWD modules with the EtherCAT field bus SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 257: Appendix

    EU5E-SWD-4D2R 116383 – EU5E-SWD-X8D 144061 – EU5E-SWD-4AX 144062 – EU5E-SWD-2A2A 144063 – EU5E-SWD-4PT 144064 – EU5E-SWD-4PT-2 172560 – M22-SWD-I1-LP01 115990 with bus termination resistor switched on M22-SWD-I2-LP01 115991 M22-SWD-I3-LP01 115992 M22-SWD-I4-LP01 115993 M22-SWD-I6-LP01 115994 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 258: Power-/Current Consumption Of The Swd Stations On Uaux

    With an LM high-power LED Continuous light – Beacon – Strobe light – With a filament lamp light module With an acoustic module Continuous or pulsed tone Continuous or pulsed tone, 8 types of – SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 259: Data Requirement (Bytes) Smartwire-Dt Modules

    PKE-SWD-CP Profile 2 PKE-SWD-CP Profile 3 PKE-SWD-CP Profile 4 NZM-XSWD-704 profile 1 NZM-XSWD-704 profile 2 NZM-XSWD-704 profile 3 NZM-XSWD-704 profile 4 EMS-...-SWD-ADP EU5E-SWD-4DX EU5E-SWD-8DX EU5E-SWD-4D4D, ...-R EU5E-SWD-4D2R EU5E-SWD-X8D EU5E-SWD-4AX EU5E-SWD-2A2A EU5E-SWD-4PT EU5E-SWD-4PT-2 M22-SWD-I1-LP01 M22-SWD-I2-LP01 M22-SWD-I3-LP01 M22-SWD-I4-LP01 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 260 13 Appendix 13.3 Data requirement (bytes) SmartWire-DT modules SmartWire-DT module Input Output M22-SWD-I6-LP01 SL4-SWD SL7-SWD SWD4-RC8-10 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 261: Color Tables M22-Swd-Led(C)-Rgb

    Magenta (100, 0, 100) Cyan (0, 100, 100) Predefined colors in ROM undefined … 20 user-defined colors programmed by Eaton … 16 colors in RAM with acyclical Smart- Color table is Wire-DT service "1" defined in … SWD-Assist SmartWire-DT module IP20 01/20 MN05006001Z-EN...

  • Page 262: Reference Table: Part No., Smartwire-Dt Vs. Eaton Catalog Number

    13 Appendix 13.5 Reference table: Part no., SmartWire-DT vs. Eaton catalog number 13.5 Reference table: Part no., SmartWire-DT vs. Eaton catalog number Type designation Eaton catalog number DILM7(C)-…(24VDC) XTCE(C)007B…TD DILM9(C)-…(24VDC) XTCE(C)009B…TD DILM12(C)-…(24VDC) XTCE(C)012B…TD DILM15(C)-…(24VDC) XTCE(C)015B…TD DILM17(C)-…(24VDC) XTCE(C)017C…TD DILM25(C)-…(24VDC) XTCE(C)025C…TD DILM32(C)-…(24VDC) XTCE(C)032C…TD...

  • Page 263: Swd Module Interoperability Requirements

    1.30 1.10 – SWD4-RC8-10 1.00 1.00 1.00 1.00 ￫ The firmware of the SmartWire-DT gateway can be updated using the SWD-Assist program. This program and firmware ver- sions are available for free at: http://www.eaton.eu/software SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 264: Fieldbus Description Files

    The latest fieldbus descriptions and predecessor versions are available for download on the Internet. To find them quickly, please go to http://www.eaton.eu/documentation and enter the gateway designation, e.g., EU5C-SWD-DP, as a search term. You will find the fieldbus description file matching the firmware version as organized in the corresponding directories.

  • Page 265: Swd-Assist

    1.80 EMS-...-SWD-ADP 1.90 EU5E-SWD-4DX 1.30 EU5E-SWD-8DX EU5E-SWD-4D4D, ...-R EU5E-SWD-4D2R EU5E-SWD-X8D 1.30 EU5E-SWD-4AX 1.30 EU5E-SWD-2A2A 1.30 EU5E-SWD-4PT 1.30 EU5E-SWD-4PT-2 1.80 NZM-XSWD-704 1.20 PKE-SWD-32 1.10 PKE-SWD-CP 1.90 PKE-SWD 1.40 SL4-SWD, SL7-SWD 1.80 SWD4-FFR-PF1-1, SWD4-FFR-ST1-1 1.70 SWD4-RC8-10 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 266: Technical Data

    Surge (IEC/EN 61131-2:2008, Level 1) Supply cables/CAN/DP bus cable Supply cables 0.5 kV Radiated RFI (IEC/EN 61131-2:2008, Level 3) Ambient climatic conditions Operating ambient temperature (IEC 60068-2) °C –25 - +55 –25 - +55 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 267 Module type – – Number of SmartWire-DT modules – – Baud Rate kbps – – Address allocation – – status display – – Porting 2 x plug, 8 pole Plug connector 2 blade terminals SWD4-8MF2 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 268 1) If contactors with a total power consumption > 3 A are connected, a power feeder module EU5C-SWD-PF1/2 has to be used. 2) If contactors with a total power consumption > 0.7 A are connected, a power feeder module EU5C-SWD-PF2 has to be used. SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 269: I/O Modules, Digital

    1 kV 1 kV SmartWire-DT cables 1 kV 1 kV 1 kV 1 kV 1 kV Surge (IEC/EN 61131-2:2008, Level – Supply cables 0.5 kV – Supply cables 0.5 kV Supply cables 0.5 kV SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 270 Low High typ. < 0.2 ms Status display inputs yellow yellow yellow yellow yellow Input supply I+, I- Specifications for - 0.16 V connection to supply voltage Output current per ≦ 0.5 input supply SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 271 – – yellow yellow yellow Potential isolation Input to SmartWire-DT – Output to SmartWire-DT – Input to input – Output to input – – Output to output – Notes 1) Minimum length 8 mm SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 272: I/O Modules, Analog

    Supply cables 1 kV Radiated RFI (IEC/EN 61131-2:2008, Level 3) Ambient climatic conditions Operating ambient temperature (IEC 60068- °C -25 - +55 -25 - +55 -25 - +55 Condensation Must be prevented with suitable measures SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 273 0 - 10 Input resistance kΩ 13.3 13.3 Current Input current 0 - 20 0 - 20 Input resistance < 250 < 250 Resolution Conversion time accuracy Electric strength Analog outputs Quantity: two-wire connection, screened) – SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 274 °C, °F, nonlinear Conversion time Cumulative error ±1 Repeat accuracy ±0.5 Potential isolation Input to SmartWire-DT Output to SmartWire-DT Input to input Output to input Output to output Notes 1) Minimum length 8 mm SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 275: Dil Contactor Modules

    Baud rate setting Automatic Status SmartWire-DT green/orange Porting Plug, 8-pole Plug connector External device plug SWD4-8SF2-5 Device supply voltage V DC, (%) 14.5 (±3) SWD module Current consumption at U ￫ Page 253 Operating mode SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 276 ≦ 2.8 ≦ 2.8 Connection type Push-In Push-In Terminal capacities solid 0.2 - 1.5 (AWG24 - AWG16) flexible with ferrule 0.25 - 1.5 0.25 - 1.5 Notes 1) own supply 2) Minimum length 8 mm SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 277: Electronic Motor-Protective Circuit-Breaker Pke-Swd

    Green Connection Plug, 8-pole Plug, 8-pole Plug connector External device plug SWD4- External device plug SWD4- 8SF2-5 8SF2-5 Device supply voltage V DC, 14.5 (±3) SWD module Current consumption at U ￫ Page 253 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 278 Connection electrical enable Cable length ≦ 2.8 – Connection type Push-In – Terminal capacities solid 0.2 - 1.5 (AWG24 - 16) – Flexible with ferrule 0.25 - 1.5 – (minimum section length 8 mm) SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 279: M22-Swd Connections

    –40 - 80 –40 - 80 –40 - 80 Relative humidity, non- 9 - 95 9 - 95 9 - 95 9 - 95 condensing (IEC/EN 60068-2- SmartWire-DT network Module type SmartWire-DT module (slave) SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 280 Mechanical shock resistance Impact (IEC/EN 60068-2-27) resis- semi-sinusoidal 15 g/11 ms tances Drop (IEC/EN 60068-2-31); drop height Free fall, packaged (IEC/EN 60068-2-32) Electromagnetic compatibility (EMC) Overvoltage category pollution degree Electrostatic discharge (IEC/EN 61131- 2:2008) SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 281 Contacts 2 changeover contacts 2 changeover contacts – Lifespan mechanical/elec- 1 x 10 1 x 10 – trical (operations) LED indicator – Diagnostics – Mounting Front mount/ Front mount/ – base fixing base fixing SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 282: Bus Termination Resistor, Switch Cabinet Leadthroughs

     200  200  500 Number of insertion cycles SWD Out – Socket, 8 pole Socket, 8-pole  500  200 Number of insertion cycles – Current consumption ￫ Page 253 (15-V-SmartWire-DT supply) SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 283: Enclosure Bushings: Plug, Socket

    (IEC/EN 60068-2-30) Connection options SWD In – Plug, 8-pole  500 Number of insertion cycles – SWD Out Socket, 8-pole –  500 Number of insertion cycles – Current consumption (15-V-SmartWire-DT supply) ￫ Page 253 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 284: Coupling, Plug

    8-pole  200  200 Number of insertion cycles SWD Out Plug, Socket, Push in terminals 8-pole 8-pole  200  200 – Number of insertion cycles Current consumption (15-V-SmartWire-DT supply) ￫ Page 253 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 285: Swd-Basemodules For Signal Towers

    Electromagnetic fields (IEC/EN 61131-2:2008) 80 - 1000 MHz 1.4 - 2 GHz 2 - 2.7 GHz Radio interference suppression (SmartWire-DT) EN55011 Class A Burst (IEC/EN 61131-2:2008, Level 3) Supply cables Signal cables SmartWire-DT cables SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 286 0.25 – 1.5 flexible with ferrule 0.25 – 1.5 UL/CSA solid or stranded 24 – 16 Rated operating voltage VDC, 24 (-15/+20) Residual ripple – max. current consumption Protection against polarity reversal Potential isolation SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 287 From device supply voltage for SmartWire-DT modules U From the light/acoustic modules Light and acoustic modules Max. quantity Max. current per module Short-circuit / overload proof yes, with diagnostics 1) Minimum length 8 mm SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 288: Nzm Circuit-Breakers

    Condensation Must be prevented with suitable measures Storage °C –40 - +70 Relative humidity, non-condensing (IEC/EN 5 - 95 60068-2-30) SmartWire-DT interface Module type SmartWire-DT module (slave) Baud rate setting Automatic Status SmartWire-DT Green SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 289 Short circuit protection – Status display outputs – Potential separation Inputs for SmartWire-DT Semi-conductor outputs for SmartWire-DT Semi-conductor outputs for inputs – Relays for SmartWire-DT – Relays for inputs – Relays for relays – SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 290 13 Appendix 13.7 Technical data SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...

  • Page 291: Index

    ......75, 99 ..... 242 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com...
  • Page 292 Protection against polarity reversal ... 18 Reference table (part no., SmartWire-DT vs. Eaton catalog number) ......258 Remote operator .
  • Page 293 Eaton is dedicated to ensuring that reliable, efficient and safe power supply is available when it’s needed most. With unparalleled knowledge of elec- trical power management across industries, experts at Eaton deliver customized, integrated solutions to solve our customers’ most critical chal- lenges.

Table of Contents
