ADM1060
HIGH VOLTAGE SUPPLY FAULT DETECT (HV SFD) REGISTERS
Table 10. Register 0xB0 HSOVTH
(Power-On Default 0xFF)
Bit Name R/W
7–0 OV7–OV0 R/W
Table 11. Register 0xB1 HSOVHYST
(Power-On Default 0x00)
Bit Name R/W
7–5 Reserved N/A
4–0 HY4–HY0 R/W
Table 14. Register 0xB4 HSSEL (Power-On Default 0x00)
Bit Name
7 Reserved
6−4 GF2−GF0
3 Reserved
2 RSEL
1−0 FS1−FS0
Description
8-Bit Digital Value for OV
Threshold on HV SFD
Description
Cannot Be Used
5-Bit Digital Value for Hysteresis
on OV Threshold of HV SFD
R/W Description
N/A Cannot Be Used
R/W GF2
0
0
0
0
1
1
1
1
N/A Cannot Be Used
W RSEL
0
1
W
FS1
0
0
1
1
Table 12. Register 0xB2 HSUVTH
(Power-On Default 0x00)
Bit Name
7–0 UV7–UV0
Table 13. Register 0xB3 HSUVHYST
(Power-On Default 0x00)
Bit Name
7–5 Reserved
4–0 HY4–HY0
GF1 GF0
0 0
0 1
1 0
1 1
0 0
0 1
1 0
1 1
Bottom of Range Top of Range
2 V 6 V
4.8 V 14.4 V
FS0 Fault Select Type
0 Overvoltage
1 Undervoltage
0 Out-of-Window
1 Not Allowed
Rev. B | Page 16 of 52
R/W Description
R/W 8-Bit Digital Value for UV
Threshold on HV SFD
R/W Description
N/A Cannot Be Used
R/W 5-Bit Digital Value for Hysteresis
on UV Threshold of HV SFD
Glitch Filter Delay (µs)
0
5
10
20
30
50
75
100
Step Size (mV)
15.6
37.6
