PART IDENTIFICATION CHART

See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part, from the PART LIST near the end of this manual. The number following the key num-
ber is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it has been
preattached. To avoid damaging parts, do not use power tools for assembly.
5/16" x 3/4"
Screw (92)––1
#8 x 1/4"
Screw Screw (94)––6
(70)––1
5/16" x 2 1/4"
Screw (81)––1
7
#8 x 3/4"
3/8" x 2 1/4"
Screw (74)––4
