iFIT IFBE13520 User Manual

Pilates reformer
Hide thumbs

Advertisement

Quick Links

Model No. IFBE13520
Serial No.
Write the serial number in the
space above for future reference.
Serial Number Decal (Under Seat)
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satisfac-
tion through direct assistance
from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
customer hot line will provide
immediate assistance, free of
charge.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
For a great selection of
new CD and MP3 workouts
Visit our website at
www.iFIT.com
or call 1-800-215-7398

Advertisement

loading
Need help?

Need help?

Do you have a question about the IFBE13520 and is the answer not in the manual?

Questions and answers

Related Manuals for iFIT IFBE13520

Summary of Contents for iFIT IFBE13520

  • Page 1 Model No. IFBE13520 Serial No. Write the serial number in the space above for future reference. USER’S MANUAL Serial Number Decal (Under Seat) QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS ............. 2 BEFORE YOU BEGIN .

  • Page 3: Before You Begin

    The model number is IFBE13520. The the exercise bench will help you to achieve the specific serial number can be found on a decal attached to the results you want.

  • Page 4: Assembly

    ASSEMBLY • As you assemble the exercise bench, make sure Make Things Easier for Yourself all parts are oriented as shown in the drawings. Everything in this manual is designed to ensure • Assembly requires two people. that the exercise bench can be assembled suc- cessfully by anyone.
  • Page 5 3. Insert the Foot Bar (32) into the end of the Inner Frame (2). Attach two Cap Legs (14) to the ends of the Foot Bar. 4. Rest the exercise bench on its side for this step. Attach the short ends of the two Headrest Frames (7) to the bottom of the Carriage (6) with four M6 x 18mm Screws (36).
  • Page 6 6. Tighten the two Carriage Tubes (11) into the holes in the Carriage (6). Slide a Shoulder Block (10) onto each Carriage Tube (11). 7. Pull the Adjustment Knob (17) out of the Inner Frame (2). Slide the Inner Frame out of the Outer Frame (1) and engage the Knob into the adjust- ment hole in the Inner Frame.
  • Page 7 9. Orient the two Pulley Housings (26) as shown. Slide the Eyebolt/Pins (19, 20) into a set of holes in the Pulley Tubes (12). Route the two Nylon Ropes (23) through the Pulley Housings (26) as shown. 10. Insert the square tips on the two Rope Storage Knobs (31) into the square holes in the Carriage Plates (42 [not shown]).

  • Page 8: Adjustments

    ADJUSTMENTS This section explains how to adjust the exercise bench. Refer to the accompanying exercise guide and video to see the correct form for each exercise. Make sure that all parts are properly tightened each time you use the exercise bench. Replace any worn parts immediately.
  • Page 9 ADDING RESISTANCE To add resistance to the movement of the Carriage (6), engage a Resistance Cord (22) to the Resistance Bracket (21) on the Inner Frame (2). To add more resistance, engage more Resistance Cords to the Resistance Bracket. STORING THE BENCH The exercise bench can be shortened when not in use.

  • Page 10: Part List

    PART LIST—Model No. IFBE13520 R1102A Key No. Qty. Description Key No. Qty. Description Outer Frame Pulley Housing Inner Frame Pulley Outer Frame Cover Rope Grip Inner Frame Cover Grip Base Carriage Frame Bearing Carriage Rope Storage Knob Headrest Frame Foot Bar...

  • Page 11: Exploded Drawing

    EXPLODED DRAWING—Model No. IFBE13520 R1102A 25 30 44 36 30 43...

  • Page 12: Ordering Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be pre- pared to give the following information: 1. the MODEL NUMBER of the product (IFBE13520) 2. the NAME of the product (iFIT SOLUTIONS PILATES REFORMER exercise bench) ™...
