DEMO MANUAL DC3186A
THEORY OF OPERATION
margin goal of 8dB or greater. Refer to the LTC3311 data
sheet and LTPowerCAD for more information on choosing
the required components.
The soft-start of the multiphase regulator is controlled by
a single cap, C12, on the master phase. After the regulator
is in regulation the SSTT pin can be used to monitor the

PARTS LIST

ITEM QTY REFERENCE
DC3186A-A Required Circuit Components
1 4 C2, C16, C23, C36
2 17 C3-C5, C10, C17-C19, C21, C24, C25,
C28, C37, C38, C41, C42, C49, C52
3 2 C6, C12
4 8 C7, C8, C20, C26, C27, C31, C43, C45
5 1 C11
6 1 C14
7 4 C30, C50, C51, C53
8 4 L1-L4
9 1 R1
10 3 R2, R11, R14
11 1 R3
12 1 R4
13 1 R6
14 1 R7
15 1 R8
16 4 R9, R15, R20, R21
17 2 R12, R13
18 4 U1-U4
Additional Demo Board Circuit Components
1 8 C1, C15, C29, C35, C39, C40, C60, C64
2 6 C9, C32, C54, C57, C61, C65
3 8 C46, C47, C55, C56, C58, C59, C62, C63 CAP ., 10µF, X7S, 6.3V, 20%, 0603
4 4 L5-L8
5 1 Q1
6 2 R16, R18
6
temperature of each IC. The master phase temperature
can be monitored at the SSTT turret and slave 1, 2, and 3
can be monitored at TP3, 4, and 6 respectively. Calculate
the die temperature with the formula below:
T (°C) =
J
PART DESCRIPTION
CAP ., 1µF, X7T, 6.3V, 20%, 0201
CAP ., 22µF, X7S, 6.3V, 20%, 0805
CAP ., 0.1µF, X7R, 16V, 10%, 0402, AEC-Q200
CAP ., 0.01µF, X7R, 6.3V, 10%, 0201
CAP ., 6.8pF, C0G/NP0, 50V, ±0.5pF, 0402
CAP ., 470pF, C0G, 50V, 5%, 0402, AEC-Q200
CAP ., 10µF, X7S, 6.3V, 20%, 0603
IND., 0.1µH, PWR, SHIELDED, 20%, 25.8A, 1.8mΩ,
4.3mm × 4.3mm, XEL4030, AEC-Q200
RES., 1M, 1%, 1/16W, 0402, AEC-Q200
RES., 100k, 1%, 1/16W, 0402, AEC-Q200
RES., 249k, 1%, 1/16W, 0402, AEC-Q200
RES., 274k, 1%, 1/16W, 0402, AEC-Q200
RES., 140k, 1%, 1/16W, 0402, AEC-Q200
RES., 100k, 5%, 1/16W, 0402, AEC-Q200
RES., 3.32k, 1%, 1/10W, 0402, AEC-Q200
RES., 0Ω, 1/16W, 0402
RES., 301k, 1%, 1/16W, 0402
IC, LOW VOLTAGE SYN. STEPDOWN REG, LQFN-18 ANALOG DEVICES, LTC3311JV#PBF
CAP ., 470µF, TANT POLY, 6.3V, 20%, 7343
CAP ., 0.1µF, X7R, 16V, 10%, 0402, AEC-Q200
IND., 100Ω AT 100MHz, FERRITE BEAD, 25%, 8A,
6mΩ, 1812
XSTR., MOSFET, N-CH, 60V, 120A, TO-263
RES., 0.02Ω, 1%, 10W, 2818, HP , METAL, SENSE,
AEC-Q200
V
SSTT
– 273
4mV
MANUFACTURER/PART NUMBER
MURATA, GRM033D70J105ME01D
TDK, C2012X7S0J226M125AC
MURATA, GCM155R71C104KA55D
AVX, 02016C103KAT2A
AVX, 04025A6R8DAT2A
TDK, CGA2B2C0G1H471J050BA
TDK, C1608X7S0J106M080AC
COILCRAFT, XEL4030-101MEB
STACKPOLE ELECTRONICS, INC.,
RMCF0402FT1M00
NIC, NRC04F1003TRF
NIC, NRC04F2493TRF
NIC, NRC04F2743TRF
NIC, NRC04F1403TRF
NIC, NRC04J104TRF
PANASONIC, ERJ2RKF3321X
VISHAY, CRCW04020000Z0ED
SAMSUNG, RC1005F3013CS
PANASONIC, 6TCE470MI
MURATA, GCM155R71C104KA55D
TDK, C1608X7S0J106M080AC
WURTH ELEKTRONIK, 74279226101
VISHAY, SUM50020E-GE3
VISHAY, WSHP2818R0200FEA
(3)
