PARTS LIST
ITEM QTY REFERENCE
12 1 R4
13 1 R6
14 1 R7
15 1 R8
16 2 R11, R15
17 2 U1, U2
Additional Demo Board Circuit Components
1 4 C9, C32, C57, C61
2 4 C15, C29, C39, C60
3 4 C58, C59, C62, C63
4 2 L6, L7
5 1 Q1
6 2 R16, R18
7 2 R17, R19
8 1 RG1
9 1 U5
Hardware: For Demo Board Only
1 12 E1-E3, E5, E12, E14-E17, E19-E21
2 11 E4, E7, E10, E13, E18, E22-E24, E26-E28 TEST POINT, TURRET, 0.094" MTG. HOLE, PCB
3 5 E6, E8, E9, E11, E25
4 1 JP1
5 4 MP1-MP4
6 5 MP5-MP9
7 10 MP10-MP19
8 5 MP20-MP24
9 1 XJP1
DEMO MANUAL DC3186A
PART DESCRIPTION
RES., 274k, 1%, 1/16W, 0402, AEC-Q200
RES., 140k, 1%, 1/16W, 0402, AEC-Q200
RES., 100k, 5%, 1/16W, 0402, AEC-Q200
RES., 3.32k, 1%, 1/10W, 0402, AEC-Q200
RES., 0Ω, 1/16W, 0402
IC, LOW VOLTAGE SYN. STEPDOWN REG, LQFN-18 ANALOG DEVICES, LTC3311JV#PBF
CAP ., 0.1µF, X7R, 16V, 10%, 0402, AEC-Q200
CAP ., 470µF, TANT POLY, 6.3V, 20%, 7343
CAP ., 10µF, X7S, 6.3V, 20%, 0603
IND., 100Ω AT 100MHz, FERRITE BEAD, 25%, 8A,
6mΩ, 1812
XSTR., MOSFET, N-CH, 60V, 120A, TO-263
RES., 0.02Ω, 1%, 10W, 2818, HP , METAL, SENSE,
AEC-Q200
RES., 10k, 5%, 1/16W, 0402, AEC-Q200
RES., 20Ω, 1%, 1/16W, 0402, AEC-Q200
IC, OPAMP BUFFER, 20MHz, ±150mA, DFN-8
TEST POINT, TURRET, 0.064" MTG. HOLE, PCB
0.062" THK
0.062" THK
STUD, #10-32, FASTENER, 0.625" LENGTH
CONN., HDR, MALE, 1x3, 2mm, VERT, ST, THT
STANDOFF , NYLON, SNAP-ON, 0.25" (6.4mm)
RING, LUG, #10, CRIMP , 8 AWG, FLAT, NON-
INSULATED, SOLDERLESS TERMINAL
NUT, HEX, #10-32, BRASS
WASHER, #10, LOCK, EXT, TIN FINISH
CONN., SHUNT, FEMALE, 2-POS, 2mm
MANUFACTURER/PART NUMBER
NIC, NRC04F2743TRF
NIC, NRC04F1403TRF
NIC, NRC04J104TRF
PANASONIC, ERJ2RKF3321X
VISHAY, CRCW04020000Z0ED
MURATA, GCM155R71C104KA55D
PANASONIC, 6TCE470MI
TDK, C1608X7S0J106M080AC
WURTH ELEKTRONIK, 74279226101
VISHAY, SUM50020E-GE3
VISHAY, WSHP2818R0200FEA
NIC, NRC04J103TRF
NIC, NRC04F20R0TRF
ANALOG DEVICES, LT1010CDD#PBF
MILL-MAX, 2308-2-00-80-00-00-07-0
MILL-MAX, 2501-2-00-80-00-00-07-0
PENCOM, PR1422
WURTH ELEKTRONIK, 62000311121
KEYSTONE, 8831
MOLEX, 0192210223
PENCOM, NU1132
PENCOM, WA4526
WURTH ELEKTRONIK, 60800213421
