  • Page 1 PulsiteLink_Instruction_Manual_0722 © Titan Enterprises Ltd www.flowmeters.co.uk...
  • Page 2 Part number: 370-008 Document ID: PulsiteLink_Instruction_Manual_0722 These instructions are intended for use with the Pulsite Link installed with App Version 1.0.2 or higher; and the Interface Software Version 4.2.0 or higher. To view the version number, click the button Intended use: •...
  • Page 3 Failure to follow these guidelines may result in damage to the equipment or personal injury. Manufacture Information: The Pulsite Link pulse convertor is designed and manufactured by: Titan Enterprises Ltd, Unit 2, 5A Coldharbour Business Park, Sherborne, Dorset, United Kingdom. DT9 4JW.

  • Page 4: Installation

    1 General • The Pulsite Link pulse convertor is intended for use pulse output devices, such as: Reed Switch • The Pulsite Link pulse convertor will provide linearized outputs of 4-20mA (active) 0-5V 0-10V • The Pulsite Link pulse convertor can also provide...
  • Page 5 © Titan Enterprises Ltd www.flowmeters.co.uk PulsiteLink_Instruction_Manual_0722...
  • Page 6 0VDC of circuit → 16 bit Analog Output 0V Adjustable flow range +mA to PLC/Display → 4-20mA ACTIVE Analog Output mA Out 0VDC of circuit → 16 bit Analog Output 0V Adjustable flow range © Titan Enterprises Ltd www.flowmeters.co.uk PulsiteLink_Instruction_Manual_0722...

  • Page 7: Wiring Diagrams

    3.1.1 Wiring Diagrams © Titan Enterprises Ltd www.flowmeters.co.uk PulsiteLink_Instruction_Manual_0722...
  • Page 8 © Titan Enterprises Ltd www.flowmeters.co.uk PulsiteLink_Instruction_Manual_0722...
  • Page 9 NOTE: Best practice is to place Pull up/ down Resistor near target device © Titan Enterprises Ltd www.flowmeters.co.uk PulsiteLink_Instruction_Manual_0722...

  • Page 10: Interface Setup

    Before use, download and install the Titan Interface Software from memory stick or the www.Flowmeters.co.uk website The Pulsite Link should be set up using the USB interface and a suitable windows-based computer. Below is a screen shot of the opening Software screen: NOTE: When correctly connected the bars will rotate in the bottom left had corner and you should see “All Controls enabled”...
  • Page 11 If more than one meter is connected to the same PC, when starting, the Interface Software will open the window to choose which you wish to connect: By opening another copy of the Titan Interface Software you can connect and modify multiple meters from the same computer.

  • Page 12: Test Outputs

    “Start Test” button and all pins will give the selected output rate for 23 seconds. 4.1.4 Software Information This displays the current software version of the Interface software and the flow meter connected. © Titan Enterprises Ltd www.flowmeters.co.uk PulsiteLink_Instruction_Manual_0722...
  • Page 13 4.2 Window Tab Descriptions On connection with the Titan Interface Software a window will open with two tabs of settings and information: User Settings: Here you can configure how you wish the meter to present the flow and outputs. Flow Details: Shows the user real time data from the meter including flow and outputs.
  • Page 14 This is intended for a circuit in which the reed relay switches to ground with a pull-up resistor. Detection: Pulse detection can be chosen for Rising edge; Falling edge or Both edges. “Both edge” detection measures both the rising and falling edges © Titan Enterprises Ltd www.flowmeters.co.uk PulsiteLink_Instruction_Manual_0722...

  • Page 15: External Connections

    K Factor Values: Enter the values of flow and pulses per litre (K factor) as found in the calibration certificate supplied with your flow meter. 4.3.3 External Connections: Within this section the user can configure pulse, analog and alarm outputs. © Titan Enterprises Ltd www.flowmeters.co.uk PulsiteLink_Instruction_Manual_0722...

  • Page 16: Pin Assignments

    In this mode the Pulse output (NPN/PNP) is sent directly on receipt of the second pulse edge received. The pulse output is direct 50:50 ratio or can be set to a specific pulse width(ms). © Titan Enterprises Ltd www.flowmeters.co.uk PulsiteLink_Instruction_Manual_0722...
  • Page 17 The INVERT checkbox will reverse the action of the alarm output. For details for each PIN see the or hover mouse over the set point to see the action of the output with the chosen settings. © Titan Enterprises Ltd www.flowmeters.co.uk PulsiteLink_Instruction_Manual_0722...
  • Page 18 (See the Alarm Logic Table). For details for each PIN see the Alarm logic table or hover mouse over the set point to see the action of the output with the chosen settings. © Titan Enterprises Ltd www.flowmeters.co.uk PulsiteLink_Instruction_Manual_0722...

  • Page 19: Analog Outputs

    Once the Analog Mode selection has been made you can enter the low and high flows for the analog outputs as required. These are numeric entries in the units and time base selected in calibration settings. © Titan Enterprises Ltd www.flowmeters.co.uk PulsiteLink_Instruction_Manual_0722...
  • Page 20 OR: If it is selected to “Output” and set to “Flow switch” the Value column will show the transistor status either “low” or “high” and the notes will show the selected switch points. • Analog: Displays the chosen analog output and value. © Titan Enterprises Ltd www.flowmeters.co.uk PulsiteLink_Instruction_Manual_0722...
  • Page 21 Output Alarm State 0VDC Alarm Triggered High Output Alarm State +VDC Invert Selected No Alarm High Output Alarm State Invert Selected Alarm Triggered Output Alarm State 0VDC Analog Analog Current 12.54 Current output (4mA-20mA) © Titan Enterprises Ltd www.flowmeters.co.uk PulsiteLink_Instruction_Manual_0722...

  • Page 22: Led Indicators

    Voltage output (0V-5V/10V) Analog Voltage 3.22 No Power No external power to meter output (0V-5V/10V) 5 LED Indicators The Pulsite Link has two LED indicators. Left Hand Side Right Hand side GREEN Power >6VDC GREEN flashing Pulse Output (only) YELLOW/GREEN Power <6VDC...

  • Page 23: Technical Specification

    (asynchronous) accuracy better than ±300 parts per ±0.01% synthesized frequency error trillion Housing IP64 ABS/PC polymer Connections 1 x USB Type A Internal 9 x 5mm Pitch Terminal connections 2 x PG9 Cable Glands © Titan Enterprises Ltd www.flowmeters.co.uk PulsiteLink_Instruction_Manual_0722...

  • Page 24: Troubleshooting

    Settings incorrect for Range Use Titan Interface software to range the analog output flow min and max points Titan Interface Software Opens but Two windows of the Either drag window out of shows not connected to meter (no Interface Software are open...
  • Page 25 Damage to USB Return to Titan Enterprises Connection for repair Titan Interface Software Software is placing the tab Go to View on the top bar showing all Tabs (User Settings; Flow window outside the monitor menu and click Restore Details;...
