TITAN INDUSTRIES
735 INDUSTRIAL LOOP ROAD
NEW LONDON WI 54961
920-982-6600
800-558-3616 OUTSIDE WI
920-982-7750 FAX
E-MAIL: sales@titanconveyors.com
Website: www.titanconveyors.com
MODEL 124
Conveyor
INSTALLATION, MAINTENANCE AND
PARTS MANUAL
For additional copies of this manual,
please visit our website at
www.titanconveyors.com.
Go to Replacement Parts/Accessories
and select Maintenance Manuals. You can then
select the manual for your model conveyor.
SERIAL NO.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 124 and is the answer not in the manual?

Questions and answers

Summary of Contents for Titan 124

  • Page 1 735 INDUSTRIAL LOOP ROAD NEW LONDON WI 54961 920-982-6600 800-558-3616 OUTSIDE WI 920-982-7750 FAX E-MAIL: sales@titanconveyors.com Website: www.titanconveyors.com MODEL 124 Conveyor INSTALLATION, MAINTENANCE AND PARTS MANUAL For additional copies of this manual, please visit our website at www.titanconveyors.com. Go to Replacement Parts/Accessories and select Maintenance Manuals.
  • Page 2 (D) No representative of TITAN has been conferred with any authority to waive, alter, vary or add to the terms of warranty state herein, without prior authorization in writing executed by an officer of the company.
  • Page 3: Table Of Contents

    This will require you to call a Titan salesperson prior to your sending back the item to get a RGA number and receive instructions on how to return the item. Other information needed at this time would be your original purchase order number, Titan serial number, job number or invoice number.
  • Page 4 Safety The Safety alert symbol is used with the signal words DANGER, WARNING and CAUTION to alert you to safety messages. They are used in safety decals on the unit and with proper operation and procedures in this manual. They alert you to the existence and relative degree of hazards. Understand the safety message.
  • Page 5: Introduction

    Titan at 920-982-6600. I. RECEIVING Upon delivery of your Titan conveyor, check the packing slip or bill of lading accompanying the unit. If any components are missing, contact Titan IMMEDIATELY with a description of the missing components along with the conveyor serial number(s).
  • Page 6: Frame Assembly

    IN ORDER FOR THE CONVEYOR TO BE STABLE, THE SUPPORTS MUST BE WARNING LAGGED TO THE FLOOR OR SUPPORT STRUCTURE. THIS IS THE CUSTOMER RESPONSIBILITY!! FRAME ASSEMBLY To start, along side the area where the conveyor is to be installed, layout the frame sections in their proper position according to the ordered description or refer to your copy of the approval drawing.
  • Page 7: Component Checklist

    Locate all take-up pulleys to their minimum take-up positions to allow for easy belt installation. As a double check, lay out belt on a level surface and pull tight. The belt should lay flat and be in a straight line. See FIGURE 4. BELT TRAVEL MODEL 124 ROLLER BED DECK BELT TRAVEL MODEL 124...
  • Page 8: Sprocket Location

    This accomplished by locating the DRIVE sprockets so that the teeth are in the odd numbered openings and locating the tail sprockets so that the teeth are in the even numbered openings. MODEL 124 WIRE MESH CONVEYORS SPROCKET LOCATION FOR WIRE MESH BELTING...
  • Page 9 The drive shaft must be perpendicular to the belt and the drive shaft and infeed sprocket must be parallel. After making sure the conveyor is cleared off and the drive sprockets are moving the belt in the correct direction, run the conveyor. Tension the belt with the infeed take-up. A GENERAL RULE FOR CORRECT BELT TENSION IS THAT THE BELT MUST CAUTION BE TIGHT ENOUGH TO MOVE YOUR PRODUCT AT FULL LOAD.
  • Page 10: Reducers

    LUBRICATING CONDITION FREQUENCY Normal 8 hr. day 2 to 3 years Light Loads Heavy 24 hr. Day Heavy Loads 1 Year Dirty Conditions Extreme Shock Loads 3 to 6 Months High Temperatures Typical lubricants that can be used: Chevron Oil Co. - SRI#2 Gulf Refining Co.
  • Page 11 2. VENTILATION - During normal operation gear reducers build up heat and pressure that MUST be vented to protect the seals and gears. If not installed at Titan, a brass vent plug contained in a small plastic bag, will be put in a box or larger bag along with fasteners sent loose for use during field installation. Remove the top most drain plug (refer to FIGURE 10) for the position of your reducer) and install the vent plug securely in place.
  • Page 12: Bearings

    BEARINGS 1. LUBRICATION - Bearings used on Titan Conveyors are normally pre-lubed for life. If customer requested, re-lube bearings are provided, the use of a #2 consistency lithium based grease is advised.
  • Page 13: Chain & Sprockets

    SAE 40 120 degrees - 140 degrees F SAE 50 REMEMBER - ALL GUARDS AND BOTTOM PANS, IF PROVIDED, MUST BE REPLACED BEFORE RUNNING CONVEYOR. TITAN INDUSTRIES IS NOT DANGER RESPONSIBLE FOR INJURIES CAUSED BY NOT COMPLYING WITH SAFETY INSTRUCTIONS.
  • Page 14 MODEL 124 WIRE MESH BELT CONVEYOR WEAR STRIP DECK 1. 3-BOLT FLANGE BEARING 18. RETURN ROLLER BRACKET 34. DRIVE BEARING PUSHER ANGLE R/H 2. CAST TAKE-UP BAR R/H 19. FRAME CONNECTING BRACKET 35. DRIVEN SPROCKET 3. INFEED SHAFT 20. FRAME SPLICE SPREADER 36.
  • Page 15 MODEL 124 WIRE MESH BELT CONVEYOR ROLLER BED DECK 15 16 1. 3-BOLT FLANGE BEARING 16. TAKE-UP CHANNEL R/H 31. DRIVE PUSHER BRACKET 2. CAST TAKE-UP BAR R/H 17. INFEED RETAINER CHANNEL 32. GUARD BACK BRACKET 3. INFEED SHAFT 18. RETURN ROLLER BRACKET 33.
  • Page 16 NEW LONDON WI 54961 920-982-6600 800-558-3616 Toll Free 920-982-7750 FAX E-MAIL: sales@titanconveyors.com Website: www.titanconveyors.com Contact Your Distributor or Titan Directly for Further Information on Other Titan Conveyor Products Slider bed conveyors  Floor to Floor belt conveyors  parts conveyors ...
