- Page 1 ® INSTRUCTION MANUAL Titan Enterprises Limited Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk...
-
Page 2: Table Of Contents
How to Enable ASCII Streaming ................11 Serial Port settings for ASCII Streaming..............11 Interface Setup......................12 Connecting Meter to PC ..................12 5.1.1 Connecting Multiple Titan Devices ..............13 5.1.2 Retrieve Settings from Meter................14 5.1.3 Save Settings to Meter ................... 14 5.1.4... - Page 3 Flow alarm switches via NPN and PNP output terminals Disclaimer: This information has been reviewed and believed to be correct at the time of publication. Titan Enterprises holds no responsibility for any inaccuracies. The material in this document is for information purposes only.
- Page 4 Failure to follow these guidelines may result in damage to the equipment or personal injury. Manufacture Information: The Pulsite Link pulse convertor is designed and manufactured by: ® Titan Enterprises Ltd, Unit 2, 5A Coldharbour Business Park, Sherborne, Dorset, United Kingdom. DT9 4JW. And conforms to: • EMC Directives (2004/108/EC) EU Directive (2014/30/EU) •...
-
Page 5: General
Flow alarm switches via NPN and PNP output terminals 2 Installation The electronics are held in an IP64 polymer case which can be mounted into a panel or using the brackets provided. Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk... - Page 6 ® Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk...
-
Page 7: Electrical
Analog Output 0V 16 Bit 0VDC of circuit → Adjustable flow range Analog Output mA Out 4-20mA ACTIVE +mA to PLC/Display → Analog Output 0V 16 Bit 0VDC of circuit → Adjustable flow range Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk... -
Page 8: Wiring Diagrams
® 3.1.1 Wiring Diagrams Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk... - Page 9 ® Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk...
-
Page 10: Usb Connection
® When using this port, care should be taken to ensure there is no chance of water ingress to the housing. USB access via the M20 cover situated between the cable glands Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk... -
Page 11: Ascii Data Stream Via Usb
“non-streaming” mode. On exiting, the software will automatically return the connected meter into ASCII streaming mode. NOTE: If the Titan Interface Software is not closed correctly or the meter is disconnected via the cable prior to closing the software, the ASCII will not be enabled. -
Page 12: Interface Setup
® 5 Interface Setup 5.1 Connecting Meter to PC Before use, download and install the Titan Interface Software from memory stick or the Website. The Pulsite Link should be set up using the USB interface and a suitable windows-based ®... -
Page 13: Connecting Multiple Titan Devices
If more than one meter is connected to the same PC, when starting, the Interface Software will open the window to choose which you wish to connect: By opening another copy of the Titan Interface Software you can connect and modify multiple meters from the same computer. -
Page 14: Retrieve Settings From Meter
To save new settings to the non-volatile memory click the and the Confirm save menu will appear before those settings are stored. Clicking Undo changes reverts all the settings to those in the Non-volatile memory. Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk... -
Page 15: Test Outputs
“Start Test” button and all PINs will give the selected output rate for 32 seconds. 5.1.5 Software Information This displays the current software version of the Interface Software and the flow meter or instrument connected. Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk... -
Page 16: Window Tab Descriptions
® 5.2 Window Tab Descriptions On connection with the Titan Interface Software a window will open with four tabs of settings and information. User Settings: Here you can configure how you wish the meter to present the flow and outputs. - Page 17 Pulse Input windows by dragging and dropping the bottom tabs away from the main window. This allows the user to view those tabs whilst adjusting the User Settings. To return all windows to docked Mode use the View drop down menu, Restore Defaults. Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk...
-
Page 18: Pulse Input Tab
Detection: Pulse detection can be chosen for Rising edge, Falling edge or Both edges of the input pulse. “Both edge” detection measures both the rising and falling edges. Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk... -
Page 19: User Settings Tab
® Output Smoothing: This selects the rate that the analog output and asynchronous pulse outputs are updated. Chose Automatic and the Pulsite Link will adjust the sampling response time to the fastest available from the Hz pulse input. Alternatively, the user can chose a single response time for the flow range of operation. -
Page 20: External Connections
Caution must be used however, as there is no temperature/density correction. Cut Off: Flow values below this level will be set to zero. 5.4.2 External Connections Within this section the user can configure pulse, analog and alarm outputs. Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk... - Page 21 Synchronous this mode pulse output (NPN/PNP) is sent directly on receipt of the second pulse edge received. The pulse output is direct 50:50 ratio or can be set to a specific pulse width(ms). Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk...
- Page 22 (See the Alarm Logic Table). For details for each PIN see the Alarm logic table or hover mouse over the set point to see the action of the output with the chosen settings. Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk...
- Page 23 Once the Analog Mode selection has been made you can enter the low and high flows for the analog outputs as required. These are numeric entries in the units and time base selected in calibration settings. Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk...
-
Page 24: Flow Details Tab
• Analog: Displays the chosen analog output and value. The chart below shows the various display messages for the operating functions. During operation only one message will be shown for each parameter. Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk... - Page 25 No external power to meter 12.54 No Power output (4mA-20mA) Analog Current Wiring disconnected 12.54 Fault output (4mA-20mA) Analog Analog Voltage 3.22 Voltage output (0V-5V/10V) Analog Voltage No external power to meter 3.22 No Power output (0V-5V/10V) Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk...
-
Page 26: Data Logging Tab
(i.e. for longer data logging periods choose 10+ second intervals to limit the size of the file created). Then click the Icon under Storage File and enter a simple filename (no spaces) at a location you desire. Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk... - Page 27 Click it to start the data logging file creation. In the bottom left corner the samples collected will be listed as the log file builds. To finish the log file, simply click Stop Logging. Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk...
-
Page 28: Led Indicators
GREEN flashing Pulse Output (only) YELLOW/GREEN Power <6VDC BLUE flashing Analog output (only) Analog output: VDC or Not Selected 4-20mA Output TURQUOISE Pulse and Analog selected flashing output connected BLUE Communication/ settings sent Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk... -
Page 29: Technical Specification
±300 parts per ±0.01% synthesized frequency error trillion USB ASCII flow data Flow information only in format chosen in 10Hz output stream User Settings of Titan Interface Software Housing IP64 ABS/PC polymer Connections 1 x USB Type A Internal... -
Page 30: Troubleshooting
Return to Titan Enterprises for repair Analog Output incorrect Voltage too low Increase power to meter to >15VDC Settings incorrect for range Use Titan Interface Software to range the analog output flow min and max points Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk... - Page 31 ® Titan Interface Software opens but Two windows of the Interface Either drag window out of shows not connected to device (no Software are open and the way or close second spinning bars in bottom left of second window is masking...
-
Page 32: Appendices
Disconnect and Re-Connect the USB to the ASCII Streaming Device Find and Open Device Properties and look to Hardware to Identify the COM Port Value. e.g. COM8 If required, Test the Streaming using the included program ASCII_Test_Pulsite_Link.exe Pulsite®Link_Instruction_Manual_0823 © Titan Enterprises Ltd 2023 www.flowmeters.co.uk... - Page 33 ® TITAN ENTERPRISES LTD. Coldharbour Business Park, Sherborne, Dorset DT4 4JW. United Kingdom Phone: +44 (0) 01935 812790 Email: sales@flowmeters.co.uk www.flowmeters.co.uk © Titan Enterprises Ltd 2023 www.flowmeters.co.uk Pulsite®Link_Instruction_Manual_0823...
