Titan Pulsite Link Instruction Manual

Hide thumbs Also See for Pulsite Link:

Instruction manual (26 pages)

Instruction manual (33 pages)

page of 42

/ 42
Bookmarks

Quick Links

Download this manual

I I N N S S T T R R U U C C T T I I O O N N M M A A N N U U A A L L

T T i i t t a a n n E E n n t t e e r r p p r r i i s s e e s s L L i i m m i i t t e e d d

P P u u l l s s i i t t e e ® ® L L i i n n k k _ _ I I n n s s t t r r u u c c t t i i o o n n _ _ M M a a n n u u a a l l _ _ 1 1 1 1 2 2 4 4

w w w w w w . . f f l l o o w w m m e e t t e e r r s s . . c c o o . . u u k k

Distributor: DDM GmbH & Co. KG

Phone: +49 661 967 962-0

Email: info@ddm-sensors.de

Web: www.ddm-sensors.de

Need help?

Do you have a question about the Pulsite Link and is the answer not in the manual?

Questions and answers

Summary of Contents for Titan Pulsite Link

Page 1 ® I I N N S S T T R R U U C C T T I I O O N N M M A A N N U U A A L L » T T i i t t a a n n E E n n t t e e r r p p r r i i s s e e s s L L i i m m i i t t e e d d P P u u l l s s i i t t e e ®...
Page 3 D D i i s s c c l l a a i i m m e e r r : : This information has been reviewed and believed to be correct at the time of publication. Titan Enterprises holds no responsibility for any inaccuracies. The material in this document is for information purposes only.
Page 4 D D e e c c l l a a r r a a t t i i o o n n : : Titan Enterprises Ltd Declare under our sole responsibility the product(s), 370-008 & 370- 009 (Pulsite Link & Pulsite Link Display) comply by application to the standards listed below: •...
Page 5 Total volume count (with Local and Remote Reset) o Flow alarm switches via NPN and PNP output terminals • The Titan Interface Software when connected can provide: o PC display of Flow Rate and Total o User configuration of input and output parameters...
Page 7 P P O O W W E E R R S S U U P P P P L L Y Y : : 1 1 5 5 - - 2 2 4 4 V V o o l l t t D D C C O O N N L L Y Y Pulsite Link without Display (Part No 370-008): Pulsite Link with Display (Part No 370-009): ©...
Page 8 ® Description Specification Terminal Connection 15-24Vdc Regulated +24VDC → Power Input +V P P o o w w e e r r S S u u p p p p l l y y Power Input 0V 0.1 amp 0VDC → Flowmeter +5V Out +VDC Supply to meter →...
Page 9 ® 3.1.1 Pulsite Link without Display (370-008): © © T T i i t t a a n n E E n n t t e e r r p p r r i i s s e e s s L L t t d d 2 2 0 0 2 2 4 4 w w w w w w .
Page 10 ® DO NOT CONNECT +V INTO THE +5V Out TERMINAL! © © T T i i t t a a n n E E n n t t e e r r p p r r i i s s e e s s L L t t d d 2 2 0 0 2 2 4 4 w w w w w w .
Page 11 ® N N O O T T E E : : Best practice is to place Pull up/ Pull down Resistor near target device © © T T i i t t a a n n E E n n t t e e r r p p r r i i s s e e s s L L t t d d 2 2 0 0 2 2 4 4 w w w w w w .
Page 12 ® 3.1.2 Pulsite Link with Display (370-009): © © T T i i t t a a n n E E n n t t e e r r p p r r i i s s e e s s L L t t d d 2 2 0 0 2 2 4 4 w w w w w w .
Page 13 ® N N O O T T E E : : Best practice is to place Pull up/ Pull down Resistor near target device © © T T i i t t a a n n E E n n t t e e r r p p r r i i s s e e s s L L t t d d 2 2 0 0 2 2 4 4 w w w w w w .
Page 14 ® Pulsite Link with Display (370-009) ONLY can receive an Input Signal via the NPN and/or PNP Terminals © © T T i i t t a a n n E E n n t t e e r r p p r r i i s s e e s s L L t t d d 2 2 0 0 2 2 4 4 w w w w w w .
Page 15 ® 3.1.3 USB Connection The housing of the Pulsite Link has an M20 screw thread gland cover situated at the USB ® connection position. This allows access to the USB connection allowing the user to change settings or datalog the Pulsite information, without the need to uninstall the unit.
Page 16 ASCII streaming mode. N N O O T T E E : : If the Titan Interface Software is not closed correctly or the meter is disconnected via the cable prior to closing the software, the ASCII will not be enabled.
Page 17 ® 5 Interface Setup 5.1 Connecting Meter to PC Before use, download and install the T T i i t t a a n n I I n n t t e e r r f f a a c c e e S S o o f f t t w w a a r r e e from the memory stick or the product page on our Website.
Page 18 If more than one meter is connected to the same PC, when starting, the Interface Software will open the window to choose which you wish to connect: By opening another copy of the Titan Interface Software, you can connect and modify multiple meters from the same computer.
Page 19 ® 5.1.2 Retrieve Settings from Meter When connected the settings will normally be automatically retrieved from the meter. If this is not the case, or the user wishes to check the meter’s saved settings against those shown in the software, they can be retrieved from the non-volatile memory of the flow meter by pressing the spy-glass icon.
Page 20 ® Once stored, the software message bar will display “Settings match meter non-volatile memory”: 5.1.4 Test Outputs This tab enables the user to manually set outputs on the outputs for testing to the target device. Once the required output is selected, click the “Start Test”...
Page 21 ® 5.2 Window Tab Descriptions On connection with the Titan Interface Software a window will open with four tabs of settings and information. U U s s e e r r S S e e t t t t i i n n g g s s : Here you can...
Page 22 ® D D a a t t a a l l o o g g g g i i n n g g : Enables the user to log the meter’s output data on the connected computer. M M u u l l t t i i p p l l e e W W i i n n d d o o w w D D i i s s p p l l a a y y To aid set up whilst operating the meter it is possible to detach the Flow Details, Datalogging and Pulse Input windows by dragging and dropping the bottom tabs away from the main window.
Page 23 ® 5.3 Pulse Input Tab (configuring flow meter pulse input) This tab allows the user to enter the calibration information and configure the operation of the flowmeter which is generating the pulse flow information. 5.3.1 Flow Meter Pulse Input Configuration R R e e e e d d R R e e l l a a y y : Use when connecting a Reed relay flow meter.
Page 24 O O u u t t p p u u t t S S m m o o o o t t h h i i n n g g : This selects the rate that the analog output and asynchronous pulse outputs are updated. Chose Automatic and the Pulsite Link will adjust the sampling response time to the fastest available from the Hz pulse input.
Page 25 ® 5.4 User Settings Tab 5.4.1 Calibration Settings Here the user can configure the units of flow measurement for the display and outputs along with the lowest flow value to be reported. (Cut off) Units: A drop down menu offers the choice of Litres, ml, gms, kg, US gallon, Imperial gallon or Custom units i.e.
Page 26 ® 5.4.2 Display Appearance (Pulsite Link with Display Only - Part Number 370-009) Mode: Allows the user to choose what is shown on the Display Mode: Offers five options for the Display: R R a a t t e e = Flow Rate only is Displayed...
Page 27 Within this section the user can configure pulse, analog and alarm outputs, as well as input control signals. PIN Assignments The options for each PIN are:  Not Used  Input (Pulsite Link with Display Only – Part No.370-009) or  Output Each of the PIN Assignments can be configured as an output pulse or alarm function, input signal function or not used.
Page 28 ® NPN and PNP Pulse and Alarm Outputs If Output is selected in PIN assignments, the output options are: • Pulse • Single or Dual flow alarm P P u u l l s s e e : : Enter the number of pulses per unit volume required.
Page 29 ® Hysteresis (%): This is used to prevent “fluttering” of the alarm signal when flow is around the threshold level. The % value is set around the Threshold value. For example: Threshold set at 1.0 and Hysteresis at 20%. The PIN will turn ON at 1.1 and off at 0.9. N N O O T T E E : : T T h h e e I I n n v v e e r r t t c c h h e e c c k k b b o o x x w w i i l l l l r r e e v v e e r r s s e e t t h h e e a a c c t t i i o o n n o o f f t t h h e e a a l l a a r r m m o o u u t t p p u u t t .
Page 30 NPN and PNP Transistors as Signal Input Switches (Pulsite Link with Display Only – Part No.370-009) The output transistors can be configured to receive a signal telling the Pulsite Link to Reset the total and/or cycle the display from Rate to Total.
Page 31 ® Analog Outputs N N O O T T E E : : F F O O R R F F U U L L L L A A N N A A L L O O G G O O U U T T P P U U T T F F U U N N C C T T I I O O N N E E X X T T E E R R N N A A L L P P O O W W E E R R O O F F > > 1 1 5 5 V V D D C C I I S S R R E E Q Q U U I I R R E E D D There are four options on the Analog Mode drop-down menu:...
Page 32 ® 5.5 Flow Details Tab The Flow Details tab displays the performance of the meter in real time. The R R e e s s u u l l t t s s D D e e t t a a i i l l s s window below the rate and total display shows various relevant operational parameters whilst the unit is operating, e.g.
Page 33 ® Output Pulse i.e. No Pulses Inactive Frequency (Hz) Output Pulse Active Frequency (Hz) No Alarm High Output Alarm State +VDC Alarm Triggered Output Alarm State 0VDC Invert Selected No Alarm Output Alarm State 0VDC Invert Selected Alarm Triggered High Output Alarm State +VDC Input Signal...
Page 34 ® 5.6 Data Logging Tab For general monitoring purposes it is possible to log the meter/instrument performance using the Data Logging Tab function. The logging is not internal to the flowmeter/instrument but stored to the connected PC and therefore only occurs whilst the PC is connected to the meter/instrument via the USB. Simply check the relevant parameter you wish to log, choose a sensible sampling period (i.e.
Page 35 ® Once all is selected correctly the Start Logging button will become enabled. Click it to start the data logging file creation. In the bottom left corner, the samples collected will be listed as the log file builds. To finish the log file, simply click Stop Logging. ©...
Page 36 NPN/PNP (Display unit only) 6.2 Magnetic Switch The Pulsite Link with display (Part No. 370-009) has a hidden magnetic switch which enables switching of the display between Flow Rate and Flow Total; and resetting of the flow Total display. Magnet Supplied with the Pulsite Link.
Page 37 6.3 LCD Display The Pulsite Link with Display (Part No.370-009) has a Reflective LCD display which will show values for Flow Rate or Flow Total and the units of rate and volume. © © T T i i t t a a n n E E n n t t e e r r p p r r i i s s e e s s L L t t d d 2 2 0 0 2 2 4 4 w w w w w w .
Page 38 ±300 parts per ±0.01% synthesized frequency error trillion USB ASCII flow data Flow information only in format chosen in 10Hz output stream User Settings of Titan Interface Software Housing IP64 ABS/PC polymer LCD Display Reflective Not backlit 6x8mm high main characters 2.5mm enunciators...
Page 39 Check wiring and supply is 15-24VDC LED does not pulse with Flow No output configured Configure analog or pulse output using Titan Interface Software No Flow Reading from input Incorrect wiring Check Pull Up or Pull Down resistor are wired correctly...
Page 40 ® Titan Interface Software opens but Two windows of the Interface Either drag window out of shows not connected to device (no Software are open and the way or close second spinning bars in bottom left of second window is masking...
Page 41 ® 9 Appendices 9.1 Setting Serial Port to Enable VCP on Windows PC Open Control Panel Devices and Printers on your PC: (Windows 11: Bluetooth & devices > Devices. Scroll down and select ”More devices and printer settings” Plug in the ASCII Streaming device and identify the New Device Highlight and Right Mouse Click to Access Properties In Advanced Tab enable VCP...
Page 42 ® TITAN ENTERPRISES LTD. Coldharbour Business Park, Sherborne, Dorset DT4 4JW. United Kingdom Phone: +44 (0) 01935 812790 Email: sales@flowmeters.co.uk www.flowmeters.co.uk © © T T i i t t a a n n E E n n t t e e r r p p r r i i s s e e s s L L t t d d 2 2 0 0 2 2 4 4 w w w w w w .
