Installation, Maintenance & Parts Manual
For
MODELS 124 & 305
Wire Mesh Conveyors
For Additional copies of this manual, please visit our website at
www.titanconveyors.com
Go to Info Center, Select the Maintenance Manual Tab
and select the manual for your model conveyor
or click on the link below.
https://www.titanconveyors.com/info-center#823236-maintenance-manuals
Titan Conveyors
735 Industrial Loop Road
New London, WI 54961
920-982-6600
800-558-3616
FAX 920-982-7750
E-mail: sales@titanconveyors.com
Website: www.titanconveyors.com
Serial No.
Go to Table of Contents

Advertisement

loading
Need help?

Need help?

Do you have a question about the 124 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Titan 124

  • Page 1 Industrial Conveyor Specialists Installation, Maintenance & Parts Manual MODELS 124 & 305 Wire Mesh Conveyors For Additional copies of this manual, please visit our website at www.titanconveyors.com Go to Info Center, Select the Maintenance Manual Tab and select the manual for your model conveyor or click on the link below.
  • Page 2 Buyer establishes to the seller’s satisfaction that any part or parts manufactured by TITAN were defec- tive at the time of shipment, TITAN will, at its own expense, repair or replace (but not install) replacement parts. For a time purpose of this warranty, one year will constitute 2080 hours of operation based on an 8 hour day.
  • Page 3 V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S...
  • Page 4 Titan at 920-982-6600. I. RECEIVING Upon delivery of your Titan conveyor, check the packing slip or bill of lading accompanying the unit. If any components are missing, contact Titan IMMEDIATELY with a description of the missing components along with the conveyor serial number(s).
  • Page 5 V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S...
  • Page 6 Locate all take-up pulleys to their minimum take-up positions to allow for easy belt installation. As a double check, lay out belt on a level surface and pull tight. The belt should lay flat and be in a straight line. See FIGURE 4. BELT TRAVEL MODEL 124 ROLLER BED DECK BELT TRAVEL MODEL 124...
  • Page 7 This accomplished by locating the DRIVE sprockets so that the teeth are MODEL 124 in the odd numbered openings and locating the tail sprockets so that the teeth are in the even numbered openings.
  • Page 8 V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S...
  • Page 9 2. VENTILATION - During normal operation gear reducers build up heat and pressure that MUST be vented to protect the seals and gears. If not installed at Titan, a brass vent plug contained in a small plastic bag, will be put in a box or larger bag along with fasteners sent loose for use during field installation. Remove the top most drain plug (refer to FIGURE 10) for the position of your reducer) and install the vent plug securely in place.
  • Page 10 ONLY compatible polyglycol lubricants should be used. Contact the factory for more information. TEMPERATURE - Most Titan Units are supplied with wormgear reducers. These units may run at temperatures between 100 degrees to 200 degrees F. (Higher temperatures are especially common during start up).
  • Page 11 V E Y O R S BEARINGS LUBRICATION - Bearings used on Titan Conveyors are normally pre-lubed for life. If customer requested, re-lube bearings are provided, the use of a #2 consistency lithium based grease is advised. Greasing Frequency should be as many times as necessary to maintain a small film of grease leaking at the seals.
  • Page 12 120 degrees - 140 degrees F SAE 50 REMEMBER - ALL GUARDS AND BOTTOM PANS, IF PROVIDED, MUST BE DANGER REPLACED BEFORE RUNNING CONVEYOR. TITAN INDUSTRIES IS NOT RESPONSIBLE FOR INJURIES CAUSED BY NOT COMPLYING WITH SAFETY INSTRUCTIONS. 12/22 V E Y O R S...
  • Page 13 V E Y O R S V E Y O R S V E Y O R S MODEL 124 WIRE MESH BELT CONVEYOR MODEL 124 WIRE MESH ROLLER BED DECK CONVEYOR ROLLER BED DECK 15 16 3-BOLT FLANGE BEARING 16. TAKE-UP CHANNEL R/H 31.
  • Page 14 V E Y O R S V E Y O R S MODEL 124 WIRE MESH BELT CONVEYOR MODEL 124 WIRE MESH WEAR STRIP DECK CONVEYOR WEAR STRIP DECK 3-BOLT FLANGE BEARING 18. RETURN ROLLER BRACKET 34. DRIVE BEARING PUSHER ANGLE R/H 2.
  • Page 15 V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S...
