Installation, Maintenance & Parts Manual
MODEL 519 - 525 - 526 - 536 - 595
Chain Driven Live Roller Conveyors
For Additional copies of this manual, please visit our website at
www.titanconveyors.com
Go to Info Center, Select the Maintenance Manual Tab
and select the manual for your model conveyor
or click on the link below.
https://www.titanconveyors.com/info-center#823236-maintenance-manuals
735 Industrial Loop Road
New London, WI 54961
E-mail: sales@titanconveyors.com
Website: www.titanconveyors.com
Serial No.
Go to Table of Contents
Industrial Conveyor Specialists
For
Titan Conveyors
920-982-6600
800-558-3616
FAX 920-982-7750
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Titan 525
Summary of Contents for Titan 525
- Page 1 Industrial Conveyor Specialists Installation, Maintenance & Parts Manual MODEL 519 - 525 - 526 - 536 - 595 Chain Driven Live Roller Conveyors For Additional copies of this manual, please visit our website at www.titanconveyors.com Go to Info Center, Select the Maintenance Manual Tab and select the manual for your model conveyor or click on the link below.
- Page 2 Page 12 ........CDLR Pop-up Chain Transfer Blow Apart Drawing (A) Seller warrants that the material in and the workmanship on the equipment manufactured by TITAN will be free from defects at time of shipment. If during the first year from the date of shipment, the Buyer establishes to the seller’s satisfaction that any part or parts manu- factured by TITAN were defective at the time of shipment, TITAN will, at its own expense, repair or replace (but not install) replacement parts.
- Page 3 V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S...
-
Page 4: Installation
Titan at 920-982-6600. I. RECEIVING Upon delivery of your Titan conveyor, check the packing slip or bill of lading accompanying the unit. If any components are missing, contact Titan IMMEDIATELY with a description of the missing components along with the conveyor serial number(s). -
Page 5: Frame Assembly
If the frame placement has not been shown Titan recommends that the drive section be placed approximately in the center of the overall conveyor length. This is especially important for conveyors over 30 foot in length. - Page 6 V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S...
-
Page 7: Maintenance
V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S... - Page 8 2. VENTILATION - During normal operation gear reducers build up heat and pressure that MUST be vented to protect the seals and gears. If not installed at Titan, a brass vent plug contained in a small plastic bag, will be put in a box or larger bag along with fasteners sent loose for use during field installation.
- Page 9 ONLY compatible polyglycol lubricants should be used. Contact the factory for more information. TEMPERATURE - Most Titan units are supplied with worm gear reducers. These units may run at temperatures between 100 degrees to 200 degrees F. (Higher temperatures are especially common during start up). There is NO NEED TO WORRY unless temperatures exceed 200 degrees F.
- Page 10 SAE 40 120 degrees - 140 degrees F SAE 50 REMEMBER - ALL GUARDS AND BOTTOM PANS, IF PROVIDED, MUST BE REPLACED BEFORE RUNNING CONVEYOR. TITAN INDUSTRIES IS NOT DANGER RESPONSIBLE FOR INjURIES CAUSED BY NOT COMPLYING WITH SAFETY INSTRUCTIONS.
- Page 11 V E Y O R S V E Y O R S V E Y O R S MODELS 519 - 525 - 526 - 535 - 595 CHAIN TO CHAIN DRIVEN LIVE ROLLER CONVEYOR OPTIONAL SIDE DRIVE OPTIONAL SIDE DRIVE 1.
- Page 12 V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S...
