Mounting Under a Desk or a Shelf
Figure 12: Aligning the Mounting Tray Hooks with the Switch
1
2
Warning
Step 5
Secure the switch to the desk mount using the three 10-32 Phillips pan-head screws provided.
Cisco Catalyst 9200CX Compact Series Switches Hardware Installation Guide
32
Switch
Mounting tray hook
To prevent airflow restriction, allow clearance around the ventilation openings to be at least: 3 in.
(7.6 cm) Statement 1076
3 Mounting tray
- -
Installing a Compact Switch
