Product Overview
Figure 1: SD Card Slot
1
2
Uplink Ports
The C9200CX compact switches provide fixed uplink ports that support 10G SFP+ and 1G SFP modules.
For information about installing an optic module, see
SFP+ uplink ports and copper uplink ports on the switch can function simultaneously.
SD Card slot in unlocked position
SD lock
Note
Carefully rotate the SD lock at 90
excessive pressure while rotating the lock to the extreme end, to prevent it from
damaging.
Cisco Catalyst 9200CX Compact Series Switches Hardware Installation Guide
3
SD Card slot in locked position
0
to lock or unlock the SD card slot. Do not not apply
Installing an SFP or SFP+ Module, on page
Uplink Ports
45. The
5
