Switch LEDs
Port Mode
STAT (port status)
SPEED
4
PoE+
Cisco Catalyst 9200CX Compact Series Switches Hardware Installation Guide
58
Ports LED Status
Off
Green
Blinking green
Alternating
green-amber
Amber
Blinking amber
10/100/1000 Off
ports
Green
Blinking green (on
for 100 ms, off for
1900 ms)
Uplink ports Off
with 1G SFP
Green
module
installed
Blinking green
Uplink ports Off
with 10G SFP+
Green
module
installed
Blinking green
Off
Green
Amber
Blinking amber
Alternating green
and amber
Link Status
No link, or port was administratively shut down.
Link present, no activity.
Activity. Port is sending or receiving data.
Link fault. Error frames can affect connectivity, and
errors such as excessive collisions, CRC errors, and
alignment and jabber errors are monitored for a
link-fault indication.
Port is blocked by Spanning Tree Protocol (STP) and
is not forwarding data.
After a port is reconfigured, the port LED can be
amber for up to 30 seconds as STP checks the switch
for possible loops.
Port is blocked by STP and is sending and receiving
data.
Port is operating at 10 Mb/s.
Port is operating at 100 Mb/s.
Port is operating at 1000 Mb/s.
Port is operating at 10 Mb/s.
Port is operating at 100 Mb/s.
Port is operating at 1000 Mb/s.
Port is not operating
Port is operating at 10 Gb/s.
Port is operating at 1 Gb/s.
PoE mode is not enabled. None of the 10/100/1000
ports have been denied power or are in a fault
condition.
PoE mode is enabled, and the port LED displays green
when the switch port is providing power.
PoE is disabled for the port.
PoE mode is off due to a fault condition.
PoE port is denied power because providing power to
the powered device exceeds the switch power capacity.
