CP-Series
G
D
ENERAL
ESCRIPTION
The DC/DC converter CP10.241-60 is designed specifically
for railway & transportation applications. It is approved
according to the EN 50155 standard, which is an
international standard covering electronic equipment
used on rolling stock for railway applications. The
standard covers aspects such as temperature, humidity,
shock, vibration, EMI and other parameters. Because of
these
requirements,
the
conformal coated pc-boards.
The unit features a DC-OK signal contact for remote
monitoring, and quick-connect spring-clamp terminals
for a reliable connection even when mechanical
vibration and shock are involved. The unit also covers an
extreme wide temperature range from -40°C up to
+70°C with full output current.
This DC/DC converter comes in a very compact housing
and requires only 39mm space on the DIN-rail due to
the high efficiency and low power losses. The high
efficiency
is
achieved
technology and other unique design techniques.
O
N
RDER
UMBERS
DC/DC converter CP10.241-60
Accessory
ZM4.WALL Wall/Panel mount bracket
ZM12.SIDE Side mount bracket
YR20.242
YR20.246
UF20.241
May 2017 / Rev. 0.1 DS-QS10.241-60-EN preliminary
All parameters are typical values specified at 24V, 8.3A output, 110Vdc input, 25°C ambient and after a 5 minutes run-in time
unless otherwise noted.
P R E L I M I N A R Y
unit
is
equipped
by
utilizing
cutting
edge
Redundancy module
Redundancy module
Buffer module
www.pulspower.com Phone +49 89 9278 0
DC/DC C
ONVERTER
EN 50155 Railway Compliant
Conformal Coated PC-boards
Quick-connect Spring-clamp Terminals
67-154Vdc Wide-range Input
Width only 39mm
Efficiency up to 94.5%
Excellent Partial Load Efficiency
Minimal Inrush Current Surge
Full Power Between -40°C and +70°C
DC-OK Relay Contact
Reverse Input Polarity Protected
3 Year Warranty
S
-
HORT
FORM
Output voltage
Adjustment range
Output current
Input voltage DC
Input voltage range
Input current DC
Input inrush current
with
Efficiency
Losses
Hold-up time
Temperature range
Size (wxhxd)
Weight
M
ARKINGS
IND. CONT. EQ.
UL 508
planned
Germany
CP10.241-60
24V, 200W, DC/DC C
D
ATA
DC 24V
24 - 28V
8.3 – 7.1A
Continuous, < +70°C
8.3 – 7.1A
For 10 minutes, < +85°C
DC 96 - 110V
- 30%/ +40%
67.2 – 154V
2.25 / 1.95A
At 96 / 110Vdc
2.5A pk
94.3 / 94.5%
At 96 / 110Vdc
12.1 / 11.6W
At 96 / 110Vdc
34ms
-40 to +70°C
39x124x117mm Without DIN-rail
620g / 1.37lb
UL 60950-1
planned
ONVERTER
EMC, LVD
planned
planned
1/27
