CP-Series
G
D
ENERAL
ESCRIPTION
The DIMENSION CP-Series units are high-end power
supplies in a medium price range without compromising
quality, reliability and performance. The CP-Series is
part of the DIMENSION power supply family. The most
outstanding
features
of
efficiency, advanced inrush current limitation, active PFC
and the wide operational temperature range.
The CP-Series includes all the essential basic functions.
The devices have a power reserve of 10% up to +60°C
and 20% up to +45°C included, which may even be used
continuously. Additionally, the CP10 can deliver three
times the nominal output current for at least 12ms
which helps to trip fuses on faulty output branches.
High immunity to transients and power surges as well as
low electromagnetic emission, a DC-OK relay contact
and a large international approval package for a variety
of applications makes this unit suitable for nearly every
situation.
O
N
RDER
UMBERS
Power Supply
CP10.481
Mechanical Accessory
ZM4.WALL Wall/panel mount bracket
ZM12.SIDE
Aug. 2017 / Rev. 1.2 DS-CP10.481-EN
All parameters are specified at 48V, 5.4A, 230Vac, 50Hz, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.
CP10.481
are
the
high
Side mount bracket
www.pulspower.com Phone +49 89 9278 0
48V, 5.4A, 260W, S
P
S
OWER
UPPLY
AC 100-240V Wide-range Input
Width only 39mm
+10% (5.4A) continuous current up to +60°C
+20% (6A) continuous current up to +45°C
Efficiency up to 95.5%
Excellent Partial Load Efficiency
PLUS
Safe Hiccup
Overload Mode
Active Power Factor Correction (PFC)
Minimal Inrush Current Surge
Full Power Between -25°C and +60°C
DC-OK Relay Contact
3 Year Warranty
S
-
D
HORT
FORM
Output voltage
DC 48V
Adjustment range
48 – 56V
Output current
6.0-5.2A
5.4-4.6A
4.0-3.4A
Derate linearely between +45°C and +70°C
Input voltage AC
AC 100-240V
Mains frequency
50-60Hz
Input current AC
2.32 / 1.20A
Power factor
0.99 / 0.98
Input voltage DC
DC 110-150V
Input current DC
2.51A
Reduce output current to 5-4.3A (48-56V) below 93.5Vdc
AC Inrush current
6 / 9A pk
Efficiency
93.8 / 95.5%
Losses
17.2 / 12.3W
Hold-up time
34 / 34ms
Temperature range
-25°C to +70°C
Size (w x h x d)
39x124x117mm
Weight
600g / 1.3lb
M
ARKINGS
For details and a complete approval list see section 20.
IND. CONT. EQ.
UL 508
IECEx
Class I Div 2
Germany
CP10.481
P
I
INGLE
HASE
NPUT
ATA
Nominal
Factory setting 48.0V
Below +45°C ambient
At +60°C ambient
At +70°C ambient
±10%
±6%
At 120 / 230Vac
At 120 / 230Vac
±20%
At 110Vdc
At 40°C 120/230Vac
At 120 / 230Vac
At 120 / 230Vac
At 120 / 230Vac
Without DIN-Rail
UL 60950-1
ATEX
Marine
1/29
