CP-Series
P
D
RODUCT
ESCRIPTION
The Dimension CP-Series are cost optimized power supplies
without compromising quality, reliability and performance. The
most outstanding features of the CP20.241–R1/-R2 units are the
high efficiency, electronic inrush current limitation, active PFC,
wide operational temperature range and the extraordinary small
size. The units include a decoupling MOSFET for building 1+1 or
N+1 redundant power supply systems. The devices also offer
PowerBoost: Power reserves of 20%, which may even be used
continuously at temperatures up to +45°C.
These redundancy power supplies come with three connection
terminal options; screw terminals, spring-clamp terminals or
plug connector terminals which allows replacement on an active
application.
CP20.242-R2 version feature an enhanced DC input voltage
range and the CP20.241-R2-C1 is additionally equipped with
conformal coated pc-boards.
With high immunity to transients and power surges, low
electromagnetic emission, a DC-OK signal contact for remote
monitoring, and a large international approval package, makes
this unit suitable for nearly every application.
O
N
RDER
UMBERS
Power Supplies
CP20.241-R1
With quick-connect spring-clamp
terminals
CP20.241-R2
With hot swappable plug
connectors (preferred item)
CP20.242-R2
Enhanced DC-Input
CP20.241-R2-C1
With conformal coated pc boards
Accessory
ZM10.WALL
Wall/panel mount bracket
Aug. 2022 / Rev. 1.1 DS-CP20.241-R2-EN - All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 20A output
load, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.
R
EDUNDANCY
▪ AC 100-240V Wide-range Input
▪ Width only 48mm
▪ Built-in Decoupling Mosfet for 1+1 and N+1 Redundancy
▪ Efficiency up to 95.2%
▪ 20% Output Power Reserves (PowerBoost)
▪ Safe Hiccup
▪ Easy Fuse Breaking– 3 times nominal current for 12ms
▪ Active Power Factor Correction (PFC)
▪ Minimal Inrush Current Surge
▪ Full Power Between -40°C and +60°C
▪ DC-OK Relay Contact
▪ Current Sharing Feature Included
▪ 3 Year Warranty
S
Output voltage
Adjustment range
Output current
PowerBoost
AC Input voltage
Mains frequency
AC Input current
Power factor
Input voltage DC
Input current DC
AC Inrush current
Efficiency
Losses
Hold-up time
Temperature range
Size (w x h x d)
Weight
M
For details or a complete approval list see chapter 20.
www.pulspower.com Phone +49 89 9278 0 Germany
CP20.241-R1, CP20.241-R2,
CP20.242-R2, CP20.241-R2-C1
24V, 20A, 480W, S
P
S
OWER
UPPLY
PLUS
Overload Mode
-
D
HORT
FORM
ATA
DC 24V
-
20A
15A
Derate linearly between +60°C and +70°C
24A
Linear decrease to nominal power between
+45°C and +60°C
AC 100-240V
50-60Hz
4.28 / 2.25A
0.99 / 0.98
DC 110-150V
DC 110-300V
4.64A / 1.66A
10 / 4.5Apk
93.8 / 95.2%
31.7 / 24.2W
32 / 32ms
-40°C to +70°C
48x124x127mm
830g
850g
AIN APPROVALS
UL 61010-2-201
P
INGLE
HASE
Nominal
Up to +60°C ambient
At +70°C ambient
Up to +45°C ambient
-15%/+10%
±6%
At 120 / 230Vac
At 120 / 230Vac
±20%
For CP20.241-xx
±20%
For CP20.242-xx
At 110 / 300Vdc
At 120 / 230Vac
At 120 / 230Vac
At 120 / 230Vac
At 120 / 230Vac
Without DIN-rail and
plug connectors
CP20.241-R1
CP20.24x-R2
1/33
