Hardware Setup
2-3 INSTALLATION GUIDE
We will now begin the installation of the mainboard. Please follow
the step-by-step procedure designed to lead you to a complete and
correct installation.
Warning: Turn off the power to the mainboard, system chassis, and
peripheral devices before performing any work on the mainboard or
system.
BEGIN THE INSTALLATION
Step 1. CPU Installation
Your SY-6IEB mainboard comes with a CPU retention set kit. The
retention set is used to hold the Pentium
the Slot 1 CPU connector on the mainboard.
Follow these instructions to install your Pentium
correctly.
1. Unpack the Retention Set Kit
Gather all of the items included in the retention set kit, as shown in
the following figure.
®
II processor attached to
8
SY-6IEB
®
II processor
