SY-6IZM/3 Motherboard Quick Start Guide Tested To Comply With FCC Standards FOR HOME OR OFFICE USE POST CONSUMER 100% RECYCLED PAPER... - Page 2 Our customers should ensure that their use of our products does not infringe upon any patents. It is the policy of Soyo Computer Inc. to respect the valid patent rights of third parties and not to infringe upon or assist others to infringe upon such rights.
- Page 3 SY-6IZM/3 Quick Start Guide Introduction Congratulations on your purchase of the SY-6IZM/3 Motherboard. This Quick Start Guide describes the steps for installing and setting up your new Motherboard. This guide is designed for all users to provide the basic steps of Motherboard setting and operation.
-
Page 4: Sy-6Izm/3 Motherboard Layout
SY-6IZM/3 Quick Start Guide SY-6IZM/3 Motherboard Layout PS/2 KB PS/2 Mouse Connector Connector CPUFAN USB 1 USB 2 Slot 1 Intel COM 1 COM2 82443 ZX Power IDE 2 IDE 1 JP44 Header Game Port RAGE Pro Winbond LINE-OUT W83977EF... -
Page 5: Installation
SY-6IZM/3 Quick Start Guide Installation To avoid damage to your Motherboard, follow these simple rules while handling this equipment: Before handling the Motherboard, ground yourself by grasping an unpainted portion of the system's metal chassis. Remove the Motherboard from its anti-static packaging. Hold it by the edges and avoid touching its components. -
Page 6: Install The Motherboard
SY-6IZM/3 Quick Start Guide Install the Motherboard Follow the steps below in order to perform the installation of your new SY-6IZM/3 Motherboard. Install the CPU Step 1. Record the working frequency of your CPU Mark your CPU Frequency: that should be clearly marked on the CPU cover. - Page 7 SY-6IZM/3 Quick Start Guide Make Connections to the Motherboard Step 2. This section tells how to connect internal peripherals and power supply to the Motherboard. Internal peripherals include IDE devices (HDD, CD-ROM), Floppy Disk Drive, Chassis Fan, Front Panel Devices (Turbo LED, Internal Speaker, Reset Button, IDE LED, and KeyLock Switch.), Wake-On-LAN card, VGA card, Sound Card, and other devices.
- Page 8 SY-6IZM/3 Quick Start Guide Configure Memory Step 3. This Motherboard features 3 x DIMM for 168-pin 3.3V unbuffered DIMM modules, providing support for up to 256MB of main memory using DIMM modules from 8MB to 128MB. Number of Memory DIMM 1...
-
Page 9: Power Button
Your system can be power on by either pressing a power button or typing in a password, which can be set in the BIOS SOYO COMBO Setup. To avoid being unable to power up the system due to of forgetting the password, you can place a jumper cap to short JP8. This will always enable the Power Button. -
Page 10: Back Panel Connector
SY-6IZM/3 Quick Start Guide Enable/Disable Onboard VGA(JP7) Step 9. The onboard VGA features of your Motherboard are controlled by jumper JP7.You can choose to enable or disable the available VGA function by setting JP7 accordingly. Leave JP7 open to enable the onboard VGA function. Then, you can plug your VGA device monitor, after the Motherboard is installed. - Page 11 Press the <Del> key during the system diagnostic checks to enter the Award BIOS Setup program From the BIOS main menu, select [SOYO COMBO] and move the cursor to the [CPU Frequency] field to set the proper working frequency Select [Save & Exit SETUP] and press <Enter> to save the configuration to the CMOS memory, and continue the boot sequence Note: SOYO does not guarantee system stability if the user over clocks the system.
-
Page 12: Quick Bios Setup
This Motherboard does not use any hardware jumpers to set the CPU frequency. Instead, CPU settings are software configurable with the BIOS [SOYO COMBO SETUP]. The [SOYO COMBO SETUP] menu combines the main CPU parameters that you need to configure, all in one menu, for a quick setup in BIOS. - Page 13 Step 1. Insert the SOYO CD into the CD-ROM drive The SOYO CD will auto-run, and the SOYO CD Start Up Menu will display as shown below. (SOYO CD Start Up Program Menu) The SOYO CD Start Up Program automatically detects which SOYO Motherboard you own and displays the corresponding model name.
- Page 14 SY-6IZM/3 Quick Start Guide Please note that if the Start Up program was unable to determine which SOYO Motherboard you own, the manual selection menu will pop up, as shown below. Then select the user's manual file that corresponds to your Motherboard model name and click OK.
- Page 15 SY-6IZM/3 Quick Start Guide The following drivers are available for Windows 95 (Driver Installation Menu) The following drivers are available for Windows 98 (Driver Installation Menu)
- Page 16 Harddisk. The busmaster drivers make use of DMA (Direct Memory Access) to relieve the CPU of this burden, thus speeding up the system. The SOYO SpeedPro driver makes use of an advanced caching algorithm, which gives it an advantage over other busmaster drivers.
- Page 17 Note: Once you have selected a driver, the system will automatically exit the SOYO CD to begin the driver installation program. When the installation is complete, most drivers require to restart your system before they can become active.
