Page 1: Quick Start Guide
SY-6IEM Mainboard Quick Start Guide Tested To Comply With FCC Standards FOR HOME OR OFFICE USE POST CONSUMER 100% RECYCLED PAPER... - Page 2 Our customers should ensure that their use of our products does not infringe upon any patents. It is the policy of Soyo Computer Inc. to respect the valid patent rights of third parties and not to infringe upon or assist others to infringe upon such rights.
- Page 3 SY-6IEM Quick Start Guide Introduction Congratulations on your purchase of the SY-6IEM Mainboard. This Quick Start Guide describes the steps for installing and setting up your new mainboard. This guide is designed for all users to provide the basic steps of mainboard setting and operation.
-
Page 4: Key Features
SY-6IEM Quick Start Guide SY-6IEM Mainboard Layout PS/2 KB PS/2 Mouse Connector Connector DIMM 1 DIMM 2 HDD LED Slot 1 for USB 2 USB 1 ® Pentium II Processor Turbo PWRBT COM 2 Reset Intel ® Power 82443 EX/LX... -
Page 5: Installation
Follow the directions in this section designed to guide you through a quick and correct installation of your new SY-6IEM Mainboard. For detailed information, please refer to SY- 6IEM Mainboard User's Guide and Technical Reference online manual included on the CD- ROM packed with your mainboard. -
Page 6: Install The Mainboard
SY-6IEM Quick Start Guide Install the Mainboard Follow the steps below in order to perform the installation of your new SY-6IEM Mainboard. Step 1. Install the CPU Record the working frequency of your CPU that Mark your CPU Frequency: should be clearly marked on the CPU cover or write your own combination in the space provided. - Page 7 Front Panel Devices (Turbo LED, Internal Speaker, Reset Button, IDE LED, and KeyLock Switch.), Wake-On-LAN card, VGA card, Sound Card, and other devices. For more details on how to connect internal and external peripherals to your new SY-6IEM Mainboard, please refer to SY-6IEM Mainboard User's Guide and Technical Reference online manual on CD-ROM.
-
Page 8: Memory Configuration
You do not need to set any jumper for the CPU frequency. Instead, CPU settings are changed through the BIOS [SOYO COMBO SETUP]. Please refer to Chapter 3 - Quick BIOS Setup for details on how to set the Pentium ®... - Page 9 SY-6IEM Quick Start Guide Step 6. Enable/Disable Onboard Sound (JP2) The onboard audio features of your mainboard are controlled by jumper JP2.You can choose to enable or disable the available sound function by setting JP2 accordingly. Short pin 2-3 on jumper JP2 to enable the onboard sound function. Then, you can plug your external audio devices such as amplified-speakers, CD-player, and microphone to the mainboard Line-out, Line-in and Mic ports right after the mainboard is installed.
-
Page 10: Quick Bios Setup
Move the cursor to the [CPU Speed] field to set the CPU working speed. Available [CPU Speed] settings on your SY-6IEM Mainboard are detailed in the following table. If you set this field to [Manual], you are then required to fill in the next two consecutive fields: (1) the CPU Ratio, and (2) the CPU Frequency. - Page 11 Step 1. Insert the SOYO CD into the CD-ROM drive The SOYO CD will auto-run, and the SOYO CD Start Up Menu will display as shown below. (SOYO CD Start Up Program Menu) The SOYO CD Start Up Program automatically detects which SOYO mainboard you own and displays the corresponding model name.
- Page 12 However, to display the list of all drivers software available with SOYO mainboards, click the Display all drivers on the SOYO CD button. Please make sure to install only the drivers adapted to your system, or otherwise this cause system malfunctions.
- Page 13 SY-6IEM Quick Start Guide The following drivers are available for Windows 95 (Driver Installation Menu) The following drivers are available for Windows 98 (Driver Installation Menu)
- Page 14 Select which driver you want to install and click OK, or click Cancel to abort the driver installation and return to the main menu. Note: Once you have selected a driver, the system will automatically exit the SOYO CD to begin the driver installation program. When the installation is complete, most drivers require to restart your system before they can become active.
-
Page 15: Onboard Sound Driver Installation
For other application programs, and if you are using an operating system other than Win95, please refer to the ESS ™ Audio Driver Installation section in SY-6IEM Mainboard User's Guide and Technical Reference online manual included on the CD-ROM. -
Page 16: Sound-Driver Installation
[Remove] button. Then, click [Refresh]. Insert the SOYO CD into the CD-ROM drive. When the “ Update Driver Wizard” appears, click [Next]. The installation wizard will prompt you on the location of the new audio driver you want to install. - Page 17 SY-6IEM Quick Start Guide ESSCFG.EXE and ESSVOL.EXE The installation of the driver will also install three files into the window’ s directory: ESSCFG.EXE, ESSVOL.EXE and ESSCFG.INI, ESSCFG.EXE, configures AudioDrive chips to make them game-ready in DOS. ESSCFG.INI stores all the potential settings available to your hardware ESSVOL.EXE sets the default mixer volume levels.
- Page 18 Fax: 44-(0)181-569 4134 Web Site: http://www.soyo.nl E-mail: sales@soyo.nl Japan Branch Office Soyo Computer (Japan) Tel: 81-3-33682188 Fax: 81-3-33682199 Web Site: http://www.soyo.co.jp E-mail: soyo@po.iijnet.or.jp Hong Kong Branch Office Soyo Hong Kong Ltd. (H.K.) Tel: 852-2710-9810 Fax: 852-2710-9078 Web Site: http://www.soyo.com.hk E-mail: rshu@hkstar.com...
