Hardware Setup
SY-6IEB
Step 10. AGP VGA Card
Insert the AGP VGA card into the AGP slot. Then connect the
monitor information cable to the AGP card back plane external
connector.
Follow the manufacturer's instructions to perform the AGP VGA
drivers installation.
Other Display Cards: Insert other types of VGA cards into the PCI
or ISA expansion slots according to card specifications.
Step 11. PCI Audio Card
Some PCI soundcards require a PC-PCI DMA channel. Attach the
5-pin cable from your creative sound blaster PCI audio card to the
SB-LINK ™ header on the mainboard. The SB-LINK ™ will forward
requests for legacy DMA channel to the PCI Bus.
Step 12. ATX Power Supply
If you are using ATX power, plug the connector from the power
directly into the 20-pin male ATX PW connector on the mainboard,
as shown in the following figure.
ATX Power
Flash BIOS
24
