Hardware Setup
SY-6IEB
Supporting Base
Support Clip
Latches (x2)
Screws (x2)
Retention Clip
2. Position the Mainboard
Locate Slot 1 on the mainboard and position the board in the
direction as shown in the following figure:
Slot 1
ATX Power
Heat Sink
CPUFAN Power
9
