QUICK START PROCEDURE
Connecting a PC to DC3089A
You can use a PC to reconfigure the power management
features of the LTM4686B such as: nominal V
gin set points, OV/UV limits, temperature fault limits,

USB CABLE

USB to
I2C/PMBus Dongle
DC1613A
Efficiency at V
90
85
80
75
70
65
60
0 2 4
OUTPUT LOAD CURRENT (A)
Figure 5. Efficiency vs Load Current on CH0
, mar-
OUT
12-PIN (J1)
CONNECTOR
Figure 4. Demo Setup with PC
= 0.5V, 650kHz
OUT
V = 3.3V
IN
V = 5V
IN
6 8 10 12 14
DC3089A F05
DEMO MANUAL DC3089A
sequencing parameters, the fault log, fault responses,
GPIOs and other functionalities. The DC1613A dongle
may be plugged when V
Input
Power Supply
VIN
LTM4686B
Demo Board
DC3089A
Efficiency at V
90
85
80
75
70
65
60
0 2 4
OUTPUT LOAD CURRENT (A)
Figure 6. Efficiency vs Load Current on CH1
is present.
IN
V
OUT0
LOAD0
LOAD1
V
OUT1
= 0.7V, 650kHz
OUT
V = 3.3V
IN
V = 5V
IN
6 8 10 12 14
DC3089A F06
dc3089a F04
