DEMO MANUAL DC3089A

PERFORMANCE SUMMARY

PARAMETER
Input Voltage Range
Output Voltage, V
OUT0
Maximum Output Current, I
OUT0
Output Voltage, V
OUT1
Maximum Output Current, I
OUT1
Typical Efficiency
Default Switching Frequency
2
Specifications are at T
CONDITIONS
V = 2.7-5.75V, I = 0A to 14A
IN OUT0
V = 2.7-5.75V, V = 0.5V to 3.6V
IN OUT0
V = 2.7-5.75V, I = 0A to 14A
IN OUT1
V = 2.7-5.75V, V = 0.5V to 3.6V
IN OUT1
V = 5V, V = 0.5V, I = 14A
IN OUT0 OUT0
V = 5V, V = 0.7V, I = 14A
IN OUT1 OUT1
= 25°C
A
VALUE
2.7V to 5.75V
0.5V to 3.6V, Default: 0.5V
14A
0.5V to 3.6V, Default: 0.7V
14A
73.5% (See Figure 5)
78.2% (See Figure 6)
650kHz
