DEMO MANUAL DC3089A
PARTS LIST
ITEM QTY REFERENCE
42 1 R53
43 2 R72, R73
44 1 R78
45 2 R69, R70
46 0 R82
47 2 STNCL1
48 1 U1
49 1 U3
50 1 U6
51 2 XJP1, XJP2
12
PART DESCRIPTION
RES., 0.01Ω, 1%, 1W, 2010, SENSE
RES., 4.99k, 1%, 1, 10W, 0603, AEC-Q200
RES., 15.8k, 1%, 1, 10W, 0603, AEC-Q200
RES., 10Ω, 1%, 1, 1/10W, 0603
RES., OPTION, 1206
TOOL, STENCIL, 700-DC3089A
IC, DUAL 10A OUTPUTS STEP-DOWN, µModule
REGULATOR, BGA
IC, MEMORY, EEPROM, 2Kb (256x8), TSSOP-8,
400kHz
IC, LOW NOISE REGULATED CHARGE, PUMP IN,
2x2 DFN
CONN., SHUNT, FEMALE, 2-POS, 2mm
MANUFACTURER, PART NUMBER
IRC, LRC-LRF2010LF-01-R010-F
TT ELECTRONICS, LRC-LRF2010LF-01-R010-F
NIC, NRC06F4991TRF
PANASONIC, ERJ3EKF4991V
VISHAY, CRCW06034K99FKEA
NIC, NRC06F1582TRF
PANASONIC, ERJ3EKF1582V
VISHAY, CRCW060315K8FKEA
NIC, NRC06F10R0TRF
PANASONIC, ERJ3EKF10R0V
VISHAY, CRCW060310R0FKEA
ADI APPROVED SUPPLIER, 830-DC3089A
ANALOG DEVICES, LTM4685EV#PBF
MICROCHIP , 24LC025-I, ST
MICROCHIP , 24LC025T-I, ST
ANALOG DEVICES, LTC3204BEDC-5#PBF
SAMTEC, 2SN-BK-G
