DEMO MANUAL DC3089A
PARTS LIST
ITEM QTY REFERENCE
Required Circuit Components
1 1 CIN1
2 0 C16, C17
3 2 C2, C15
4 6 COUT1, COUT2, COUT3, COUT6,
COUT7, COUT8
5 2 C1, C14
6 4 CIN2, CIN3, CIN4, CIN5
7 8 COUT4, COUT5, COUT9, COUT10,
COUT11, COUT12, COUT13,
COUT14
8 2 CIN8, CIN9
9 2 COUT15, COUT16
10 3 C21, C22, C24
11 1 C23
12 1 C26
13 2 C27, C28
14 2 C29, C30
15 1 C31
16 0 D1, D2
17 1 D8
10
PART DESCRIPTION
CAP ., 150µF, ALUM. ELECT., 35V, 20%, 8x10.2mm
SMD, RADIAL, AEC-Q200
CAP ., OPTION, 0603
CAP ., 100pF, COG, 25V, 5%, 0603
CAP ., 100µF, X5R, 6.3V, 20%, 1206
CAP ., 1500pF, X7R, 100V, 10%, 0603
CAP ., 22µF, X5R, 25V, 10%, 1206
CAP ., 180µF, ALUM POLY, 4V, 20%, SMD,
7.3x4.3mm
CAP ., 2.2µF, X7R, 25V, 10%, 0805
CAP ., 47µF, X5R, 6.3V, 20%, 0805
CAP ., 1µF, X5R, 25V, 10%, 0603
CAP ., 1µF, X7R, 25V, 10%, 0805
CAP ., 0.1µF, X5R, 25V, 10%, 0603
CAP ., 0.01µF, X5R, 25V, 10%, 0603
CAP ., 4.7µF, X5R, 16V, 10%, 0603
CAP ., 2.2µF, X7R, 10V, 10%, 0603
DIODE, OPTION, SOD-323
DIODE, SCHOTTKY, 20V, 0.5A, SOD-882,
LEADLESS
MANUFACTURER, PART NUMBER
PANASONIC, EEHZA1V151P
KEMET, C0603X101J3GACAUTO
VISHAY, VJ0603A101JXXPW1BC
AVX, 06033U101JAT2A
AVX, 12066D107MAT2A
KEMET, C1206C107M9PAC7800
KEMET, C1206C107M9PACTU
MURATA, GRM31CR60J107ME39L
NIC, NMC1206X5R107M6.3TRPLPF
TDK, C3216X5R0J107M160AB
AVX, 06031C152KAT2A
WURTH, 885012206109
AVX, 12063D226KAT2A
MURATA, GRM31CR61E226KE15L
SAMSUNG, CL31A226KAHNNNE
YAGEO, CC1206KKX5R8BB226
PANASONIC, EEF-CT0G181R
PANASONIC, EEFCT0G181R
AVX, 08053C225KAT2A
KEMET, C0805C225K3RACTU
NIC, NMC0805X7R225K25TRPLPF
TDK, C2012X7R1V225K125AE
AVX, 08056D476KAT2A
MURATA, GRM219R60J476ME44
AVX, 06033D105KAT2A
NIC, NMC0603X5R105K25TRPF
TAIYO YUDEN, TMK107BJ105KA-T
AVX, 08053C105KAT2A
WURTH, 885012207078
AVX, 06033D104KAT2A
SAMSUNG, CL10A104KA8NNNC
TAIYO YUDEN, TMK107BJ104KA-T
AVX, 06033D103KAT2A
TDK, C1608X7R1E103K080AA
AVX, 0603YD475KAT2A
MURATA, GRM188R61C475KAAJD
MURATA, GRM188R61C475KE11D
TDK, C1608X5R1C475K080AC
AVX, 0603ZC225KAT2A
MURATA, GRM188R71A225KE15D
TDK, C1608X7R1A225K080AC
YAGEO, CC0603KRX7R6BB225
NEXPERIA, PMEG2005AEL, 315
