2.4.1.1 Range Offset

This parameter gives you the opportunity to compensate application-specific distance offsets. If the ToF sensor is part of a
system that has another reference edge for assessing the distance, the offset between sensor and this reference edge must
be defined with the Range Offset parameter.
Formula: Range = RawRange – RangeOffset
Figure 36: Range Offset
Be careful when setting this parameter because range values may turn negative.
NOTE:
