AFBR-S50 User Guide
Figure 14: Data Logger Recording Options
The amount of data of the data logger output file can be changed by choosing a different data output mode from
NOTE:
the Configuration API in the API section if Advanced Mode is enabled in tab options, section API Options (see also
Section 2.4.3, Options
For formatting reasons, open the created log file either with an advanced text application (for example, Notepad++) or import
it directly into a data analysis program. Another helpful debug feature is to perform a Serial Trace of all the bus transfers
between the microcontroller and the connected device. After the start of a Serial Trace, the application asks for a path to
save the Serial Trace Data. Both the Measurement Log Data and the Serial Trace are saved as .txt files.
Figure 15: View Menu
Single view modules can be enabled or disabled in the Explorer app with the View menu.
The Help menu is used to flash the current AFBR-S50 device software to the connected microcontroller, open the latest
status message log, reset the application values to default, and provide additional links to all necessary documentation on
the SDK.
Broadcom
Tab).
Evaluation Kit Quick Start Guide
AFBR-S50-EK-UG102
11
