Calibration Interval

The hourglass icon
elapsed/remaining time for the calibration. The same information is also
displayed in a text message when you open the calibration option.
WARNING
When the calibration interval has completely lapsed, YOU WILL NOT
BE ABLE TO MAKE A MEASUREMENT UNTIL YOU RECALIBRATE
THE INSTRUMENT.
This information refers to the aperture condition currently selected.
You may need to recalibrate the instrument when you change the
aperture selection.

Measuring Samples

Pressing the Measure button on the back of the unit at any time will
immediately trigger a measurement, regardless of the program option
currently active.
The measurement procedure is as follows:

Position the stapler foot over the area to be measured. The
color must completely fill the circle in the center of the stapler
foot.

Press the RED Measure button on the back of the instrument.

Measure Standard/Measure Batch

The Measure/Select Standard
buttons on the Control Panel have several functions.

To assign a name to the sample before the measurement is
made.

To retrieve a standard/batch previously stored.

To override the next sample type in the measurement
sequence. See "Sample Type" for details.

Sample Type

Each time you press the Measure button, the system automatically
assigns a sample type, standard or batch, to the measurement. An icon
in the lower left corner of the screen identifies the sample type that will
be assigned to the next measurement.
CHECK II Quick Start Guide
at the top of the screen indicates
and Measure/Select Batch
Measuring Samples  25
