Project Timber Evolution My Den Building Instructions page 2

10x8 Evolution My Den
Metal Roof
Side Window Opening (RIGHT)
Metal Roof
Floor Assembly
shown
position
610mm
1000mm
505mm
1467mm x 1217mm (4)
Back Panels Front Panels
10x8 Floor Plan
position position
1220mm 585mm 1220mm
1220mm 610mm 610mm
1220mm
Single
585mm
Door
610mm
Panel
Side
Window
Opening
(RIGHT)
Door
610mm 610mm
Position
610mm
(LEFT)
Front of Building
