Project Timber Evolution My Den Building Instructions page 14

38 Bottom Panel Stages
Check the corner
gap of panel
Front
Slide and fit the Bottom
Panel (LEFT) to the side
*Check the Door Panel
of door section and side
and Front Window
Panels position options
gable panels.
(LEFT or RIGHT).
41 Glazing Unit fixing
Front
Secure the
Glazing
Unit.
S70
Use 70mm
Screws
through
the back
rebate
Pilot drill holes S70
before fixing
ID: PT18490
S70
Door on the Left Panel Stages
Bottom Panel Stages
39
ID: PT25547
ID: PT25547
Pilot drill holes
before fixing
42
Front
S70
S70
Secure the Bottom Panel
50mm
Screws
Front
Glazing Unit fixing
ID: PT18490
Align and fix the
second Glazing Unit.
S70
70mm
Screws
S70
S70
Pilot drill holes
before fixing
Glazing Unit fixing
40
Front
*Check the Front Window
Panels position option
(LEFT or RIGHT).
Position and align
the Glazing Unit
43 Glazing Unit fixing
Front
ID: PT18490
70mm
S70
Screws
S70
S70
Pilot drill holes
before fixing
S70
