Project Timber Evolution My Den Building Instructions page 15

44 Glazing Unit fixing
S70
S70
S70
Front
47 Top Panel Stages
Top Panel fixing
Front
S70 S70
S70
S70
70mm
Screws
Pilot drill holes
before fixing
45
Glazing Unit
fixing
70mm
Screws
ID: PT18490
S70
Front
Position the Top
Panel to the top
Pilot drill holes
of glazing units
before fixing
48
S70
Side
80mm
Screws
60mm x 16mm
S70
x 2135mm
Corner Trim
Top Panel Stages
Check the corner
gap of panel
FRONT - Corner Trims (CT)
Front
ID: PT21078
Side
Front
Top Panel Stages
46
Fix and secure
the Top Panel
ID: PT20322
Front
49 BACK - Corner Trims (CT)
Side
Back
80mm
ID: PT21078
Screws
60mm x 16mm
x 2050mm
Side
Corner Trim
50mm
Screws
Pilot drill holes
before fixing
Back
