Graphics Lcd (J13) - Altera Cyclone III 3C120 Reference Manual

Chapter 2: Board Components
General User Interfaces
Table 2–38. Character LCD Display Component Reference and Manufacturing Information
Board
Reference
J4
© March 2009
