Device Control
Front Panel Control Buttons
Input Select/ Output Select
The front panel features eight input and eight output
selection buttons for switching sources and displays.
Please see the device switching examples below.
1. To configure 1 input to 1 output
Example: Source device on Input 1 to display on
Output 3
- Press Inputs 1 + Outputs 3 + Enter button
2. To configure 1 input to multiple outputs
Example: Source device on Input 1 to display on
Outputs 3, 6, and 7
- Press Inputs 1 + Outputs 3, Outputs 6, Outputs 7+
Enter button
3. To configure 1 input to All outputs
Example: Source device on Input 2 to display on All
Outputs
- Press Inputs 2 + All + Enter button
Note: The selected buttons LED indicators will blink
three times then turn off when switching is successful. If
switching fails all LEDs will turn off immediately.
Input Device / Output Device Recognition
Press any Output Select button and the corresponding
Input Select LED will light up.
Lock
Hold down the lock button for 3 seconds to disable all the
front panel buttons. Hold down the button again for 3
seconds to unlock the buttons.
