gofanco Matrix88HD20-Pro User Manual page 11

Examples
Send the source device on HDMI In 3 to the display on
HDMI Out 2
INPUTS: Press button 3
OUTPUTS: Press button 2
Press Enter to execute the change
Send the source device on HDMI In 1 to the displays on
HDMI Out 1 & 4
INPUTS: Press button 1
OUTPUTS: Press both buttons 1 & 4
Press the Enter button to execute the change
Send the source device on HDMI In 4 to all displays
INPUTS: Press button 4
OUTPUTS: Press the All button
Press the Enter button to execute the change
11
