6.6 UNITY 3.0 - VERSION (-I) STANDARD OPTIONS -
JAPAN
▪ Analog TV + FM Radio
▪ Digital TV ISDB-T (JAPAN) with Smart Card reader
▪ IPTV (LAN- mpeg over UDP/RTP) not encrypted + Internet via LAN
▪ IPTV (LAN- mpeg over UDP/RTP) not encrypted + Internet via LAN (different VLAN)-> (ADD-
ON A0000897)
▪ IPTV (LAN -mpeg over UDP/RTP) not encrypted + Internet via Wi-Fi (ADD-ON A0000897)
DIGITAL IPTV - ENCRYPTED
▪ Pro:IDIOM : IPTV SD/HD (LAN mpeg over UDP/RTP) ENCRYPTED Pro:IDIOM -(ADD-ON
A0000897)
▪ IPTV (other encryption standards): centrally convert the signal to IPTV WITHOUT encryption
INTERNET IPTV (E.G. NETFLIX)
ANDROID APP (FREE) – Compatibility check
SUPPORTED ANALOGIC STANDARDS: NTSC M.
Broadcast System
Digital Signal Level
(COAX)
Codecs
Video Resolutions
Audio
IPTV
- 36 -
STANDARD ISDB-T - JAPAN / ANALOG / IPTV
UNITY3.0 - VERSION "-I"
DIGITAL TV: ISDB-T
ANALOG TV: YES
RADIO FM: YES
RF INPUT: F-Type connector
INPUT INPEDENCE: 75 Ohm
ISDB-T
MPEG-2 MP@ML & MP@HL format ISO/IEC 13818-2
Decodes up to 720p and 1080i
MPEG-1 layer I/II, MPEG-2 layer II, MPEG-2 AAC and AC3 Dolby®
Digital
INPUT: Ethernet 10/100/1000 BaseT via RJ-45 shielded connector
PROTOCOLS: mpeg TS over UDP/RTP protocols
Supports IP and RF tuning: direct IPTV, RF only, and mixed RF/IP
SKILLRUN (DJJ) Pre-Installation Requirements
MIN: -60 dBm / 49 dBμV / -11 dBmV (SNR> 23)
MAX: 0 dBm / 109 dBμV / 49 dBmV (SNR> 23)
Tab. 13
