- Page 1 S E L E C T I O N T H E S T R E N G T H E V O L U T I O N Delts Machine User manual Compliant EEC 93/42 Directive All equipment...
-
Page 2: Table Of Contents
Contents Identification of the manufacturer and equipment ......3 Description of the equipment ............4 Technical data ................... 5 Safety devices and warnings ............6 Place of installation ................8 Fitting the number holder ..............9 Lifting and moving the equipment ........... 10 Adjusting the equipment .............. -
Page 3: Identification Of The Manufacturer And Equipment
Identification of the manufacturer and equipment The equipment and manufacturer identification plate, placed behind the backrest, gives the following details: A Manufacturer’s name and address B CE Mark C Serial number D Maximum user weight E Equipment classification F Consultation of user manual required Delts Machine... -
Page 4: Description Of The Equipment
Description of the equipment A Seat: where the user sits to perform the exercise. Its position can be adjusted using lever (E). B Levers: operated by the user by means of the pads (G). C Weight stack: the levers (B), operated by the user, move the weights along two guides by means of a cable. A pin (H) is used to select the workload, to adjust the exercise effort level. -
Page 5: Technical Data
Technical data 1185 mm 1400 mm (47") (55") 1180 mm (47") 296 kg (652 lb) 330 kg (727 lb) 100 kg (200 lb) 130 kg (260 lb) Delts Machine... -
Page 6: Safety Devices And Warnings
Safety devices and warnings The maximum user weight is 180 kg (397 lb). The weight stack is covered on the outside by protective panels. The equipment has no sharp corners. All parts which come into contact with the user’s body are suitably protected with rubber coverings or padding. Pay particular attention to the parts of the equipment with labels indicating “BEWARE OF CRUSHING”. - Page 7 Safety devices and warnings WArnInGS Attention must be paid to the labels attached to the equipment, as they provide information about possible risks and hazards. We recommend immediately replacing the labels when they become damaged or difficult to read. Delts Machine...
-
Page 8: Place Of Installation
Place of installation To ensure safe, comfortable and effective use of the equipment, the place of installation must comply with certain specific requirements; in particular, before choosing where to install the equipment we recommend that you check that the following conditions are available: a temperature between +10°C and +25°C;... -
Page 9: Fitting The Number Holder
Fitting the number holder The number holder must be fixed immediately underneath the top: standing facing the equipment, attach the number holder on the left, on the cover of guide rail (A). Find the place where the two screws (B) are to be inserted. Attach the number holder using the two screws;... -
Page 10: Lifting And Moving The Equipment
Lifting and moving the equipment Snap-on castors (optional) must be used to move the equipment. WArnInG Move the equipment very carefully, because it may become unstable and tip over. The castors for moving the equipment snap on under the feet of the equipment, after it has been raised, and are held in place by the special straps. - Page 11 Lifting and moving the equipment Proceeding in the same way, lift the equipment on seat side and insert the swivel castors. Lastly, lift the equipment again, remove the safety wedges and place the wheels on the floor. WArnInGS When moving the equipment, we recommend pushing it only from the weight stack side, and not from any other side.
- Page 12 Lifting and moving the equipment To facilitate passage through narrow doorways, transport and handling, it is possible to remove the seat: operate lever (B) and completely lower the seat (C); remove one of the three screws (D) and screw it into the hole behind the tube (E) of the seat;...
-
Page 13: Adjusting The Equipment
Adjusting the equipment After the equipment has been positioned on the floor, check that it is level. An adjuster screw, indicated by two embossed arrows, is supplied for this purpose under foot (A). Raise the equipment and adjust the screw until the equipment is level. WArnInG Given the weight of the equipment, we recommend that it should always be lifted by more than one person. -
Page 14: Routine Maintenance
Call the Technogym Technical Support Service for instructions on any maintenance operations not described in this manual. Delts Machine... -
Page 15: Replacing The Padded Parts
replacing the padded parts If any of the padding shows signs of wear, especially in the interests of hygiene, we recommend replacing it completely. To replace seats and backrests loosen the screws on the opposite side to the padding. The handgrips are removed by unscrewing them. In order to replace the elbow pads unscrew the screws (A) and remove the covers (B);... -
Page 16: Replacing The Cable
Cables must always be replaced at the first sign of wear, even if only the outer rubber protection is worn. WArnInGS Carefully check the state of the cables once a month. ALWAYS use cables supplied directly by Technogym. To replace the cable, proceed as follows: remove the protective panel covering the weight stack, following the instructions found in the paragraph headed Removing the front weight stack panel;... -
Page 17: Adjusting The Cable Tension
Adjusting the cable tension To take up some of the slack in the weight stack cable proceed as follows: remove the front protective panel on the weight stack; use an Allen key (A) and an open spanner (B); loosen the nut (C) securing the screw (D) by half a turn in an anticlockwise direction;... -
Page 18: Removing The Front Protective Weight Stack Panel
removing the front protective weight stack panel The front protective panel on the weight stack is fixed to the frame by eight screws. To remove the panel, you must: unscrew the four screws (A); unscrew the four screws (B) while holding the panel with one hand; remove the panel. -
Page 19: Technical Service
When contacting the Technogym Technical Support Service, please specify the following details: equipment model, date of purchase, serial number, precise description of the problem. WArnInG Any operations carried out by persons not authorized by Technogym on the equipment will invalidate the warranty. Delts Machine... -
Page 20: Storage
Storage If the equipment will not be used for a prolonged period, we recommend storing it: in a clean and dry place, covered with a cloth to protect it from dust; in an environment with a temperature between +10°C and +25°C and humidity between 20% and 90%. Use the original packing materials, to better preserve the equipment. -
Page 21: Disposal
Disposal It is always good practice to ensure that the equipment can never constitute a hazard; therefore do not leave the equipment where children may play with it. Do not dump the equipment in the environment, or in public areas or private areas accessible to the public. The equipment is made from recyclable materials such as steel, aluminium and plastic, which must be disposed of in the manner prescribed by the urban refuse collection regulations in force, by firms specialised in urban and environmental hygiene. -
Page 22: Using The Equipment
Using the equipment Sit down and pull the lever (A) under the front of the seat to set the height so that the shoulders are in line with the axis of the leverfulcrums. To lower the seat you can remain seated; to raise it, lift your weight off the seat and adjust accordingly. Select the workload with the pin (B). - Page 23 Using the equipment Raise your arms sideways, keeping the forearms against the padding. Control the speed of movement constantly; the return speed should be slower than the outward speed. Make the return movement slowly, until you feel the strain taken off the weight. At the end of the exercise, release the handles and raise the levers to make it easier to stand up.
