Range Of Framerate And Bitrate Of Dvb-T Hd Video Stream; Unity 3.0 - Version (-A) Standard Options - Usa/Canada - Technogym SKILLRUN UNITY 5000 Instructions Manual

SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
Codecs
Video Resolutions
Audio
Analog TV
Radio FM
6.4.1 RANGE OF FRAMERATE AND BITRATE OF DVB-T HD
VIDEO STREAM
Conform framerate
Conform bitrate
6.5 UNITY 3.0 - VERSION (-A) STANDARD OPTIONS -
USA/CANADA
NOT ENCRYPTED
▪ Analog TV (e.g. NTSC) + FM Radio
▪ Digital TV (coax ATSC) not encrypted Version
▪ Cable TV (coax QAM-B 64/256) not encrypted
▪ IPTV (LAN- mpeg over UDP/RTP) not encrypted + Internet via LAN
▪ IPTV (LAN- mpeg over UDP/RTP) not encrypted + Internet via LAN (different VLAN)-> (ADD-
ON A0000897)
▪ IPTV (LAN -mpeg over UDP/RTP) not encrypted + Internet via Wi-Fi (ADD-ON A0000897)
ENCRYPTED
DIGITAL COAX - ENCRYPTED
▪ Pro:IDIOM: Cable TV (coax QAM-B 64/256) ENCRYPTED Pro:IDIOM - (ADD-ON A0000845
▪ Other encryption standards:
Centrally convert the signal to COAX analog/digital (QAM) without encryption
Install an external Set Top Box: HDMI-IN input ready for external STB (ADD-ON A0000915)
DIGITAL IPTV - ENCRYPTED
DVB-T2 HEVC
UNITY3.0 VERSION "-T" + UPGRADE KIT A0000854
MPEG-2, MPEG-4 H264/AVC - H.265/HEVC decoding
Decodes up to 720p and 1080p@50/60Hz
Mpeg1 (Layer I/II/III), Mpeg2(Layer I/II), Dolby D, Dolby D+, HE-
AACv1, MP3
NO
NO
DVB-T HD video stream
24fps, 25fps or 30fps
from 10 Mbps to 20 Mbps
Tab. 8
Tab. 9
- 33 -
