- Page 1 E L E M E N T E S S E N T I A L S T R E N G T H Lat Machine User manual All equipment...
-
Page 2: Table Of Contents
Contents Identification of the manufacturer and the equipment ....3 Description of the equipment ............ 4 Technical data ................5 Safety labels and warnings ............6 Place of installation ..............7 Unpacking ................. 8 Lifting and handling the equipment ........... 9 Routine maintenance ............. -
Page 3: Identification Of The Manufacturer And The Equipment
Identification of the manufacturer and the equipment The identification plate of the equipment and manufacturer, affixed on the frame behind the weight stack, gives the following details: A Name and address of the manufacturer B CE Mark C Serial number D Cautions and maximum user weight E Equipment classification ELEMENT+... -
Page 4: Description Of The Equipment
Description of the equipment Seat (A): where the user sits to perform the exercise. Bar (B): moved by the user to perform the exercise. Rollers (C): allow you to use workloads equal to or higher than body weight. Their position is adjustable in depth by means of the rollers lever (D) after having released it by operating the button positioned on it. -
Page 5: Technical Data
Technical data 1202 mm (47") 1205 mm 799 mm (47") (31") 1421 mm (56") 205 kg (596 lb) 80 kg (160 lb) Lat Machine... -
Page 6: Safety Labels And Warnings
Safety labels and warnings The equipment does not have any sharp corners. All the parts which come into contact with the body are adequately protected with rubber coverings or padding. WARnIngS During all operations involving transport, maintenance and cleaning, pay attention to any part of the equipment where body parts may become trapped. -
Page 7: Place Of Installation
Place of installation To guarantee safe, comfortable and effective use of the equipment, the place of installation must comply with certain specific requirements; in particular, before choosing where to install the equipment it is recommended to check the following: temperature between +10°C and +25°C; sufficient ventilation to maintain a humidity level between 20% and 90%, when the equipment is in use;... -
Page 8: Unpacking
Unpacking The equipment is supplied fully assembled in a carton and protected by cellophane wrapping, and secured to a pallet. The equipment can be lifted and handled using normal lifting machine. In order to ensure the safety of persons and property, carefully determine the lifting and handling machine used as a function of the place of installation. -
Page 9: Lifting And Handling The Equipment
Lifting and handling the equipment To move the equipment, use normal lifting and handling machine. WARnIng The equipment must be moved with great care, due to the risk of it tipping over. Lift the equipment from the weight stack side, as shown in the figure. WARnIngS given the weight of the equipment, we recommend that more than one person be involved in lifting it. -
Page 10: Routine Maintenance
For maintenance actions not described in this manual, call in the Technogym Technical Service. Lat Machine... -
Page 11: Replacing The Padded Components
Replacing the padded components If any of the padded components show signs of wear, it is advisable, especially in the interests of hygiene, to replace them completely. In order to replace the seat loosen the screws on the opposite side to the padding. In order to replace the roller pads remove the cover (A) and unscrew the screw (B);... -
Page 12: Replacing The Cable
Replacing the cable To replace the cable, proceed as follows: dismantle the bar; raise the rubber gaiter (A); unscrew the screws (B) and extract the cable from the attachment (C); back off the lock nut (D) and unscrew the adjuster (E); extract the cable from the adjuster side;... - Page 13 Replacing the cable insert the new cable beginning on the adjuster side (follow the original path of the cable as shown in the figure); insert a thickness of approx. 10 mm (1/2”) under the first weight of the weight stack; Lat Machine cont.
- Page 14 (D); remove 10 mm thickness (1/2”) from the weight stack. WARnIng ALWAYS use cables supplied directly by Technogym. The cables must always be replaced at the first sign of wear, even if it only affects the outer rubber protection.
-
Page 15: Adjusting Cable Tension
Adjusting cable tension It is possible to take up some of the slack in the weight stack cable using the adjuster (E), after loosening the lock nut (D). WARnIng To pull the cable taut after replacement, it may be helpful, when tightening the screws (A), to insert a thickness of approx. -
Page 16: Replacing The Spring Hook
When replacing, always use a spring hook supplied directly by Technogym. If it is impossible to obtain an original part, use a spring hook that strictly meets the following minimum requirements: materials used: AISI 316 stainless steel;... -
Page 17: Technical Service
When contacting the Technogym Technical Support Service, please specify the following details: equipment model, date of purchase, serial number, precise description of the problem. WARnIng Any operations on the equipment carried out by persons not authorized by Technogym will invalidate the warranty. Lat Machine... -
Page 18: Storage
Storage If the equipment will not be used for a prolonged period, it is recommended to store it: in a clean and dry place, covered with a cloth to protect it from dust; in an environment with a temperature between +10°C and +25°C and a humidity between 20% and 90%. For correct storage, use the original packing materials. -
Page 19: Using The Equipment
Using the equipment Sit down and position your legs underneath the roller pads. To adjust the height of the roller pads release the rollers lever (A) by operating the button positioned on it. Select the workload with the pin (B). Grasp the bar evenly. - Page 20 Using the equipment Pull the bar down; make sure that your spine does not bend during the exercise. Maintain a smooth controlled speed through the movement while staying in control of the weight. At the end of the exercise return the weight stack to the starting position. Lat Machine...
