Digital Watchdog MEGApix Flex DWC-PVX20WATW User Manual page 43

Setup - Network Setup
RTSP Information
2
3
4
5
6
7
VIN Source - Each of the camera's sensors must be set up separately. Select between Video 1 ~ Video 4 for
1
each of the camera's sensors. The settings below will apply to that sensor only.
Click 'Apply' to save the settings before changing to another video source.
Target Stream - Select the stream you want to set.
2
Time out - Set the RTSP time out.
3
The session is disconnected after the specified time-out.
QoS Setting - Set the quality of service to ensure data transfer performance.
4
RTP Multicast - Check RTP Multicast Start/Stop. To activate RTP Multicast.
5
1. Click the "On" button.
2. Enter accessible RTP Multicast IP, the port for video stream control and RTP packet TTL.
3. Click the "Apply" button.
It is possible to set each RTP Multicast for CH1~3.
Click 'Apply' to save all settings.
6
Click this button when completed setup each channel.
It shows RTSP Connection information.
7
43
