Digital Watchdog MEGApix Flex DWC-PVX20WATW User Manual page 18

Setup - Video & Audio Setup
Video Configuration
1
2
3
4
5
6
VIN Source - Each of the camera's sensors must be set up separately. Select between Video 1 ~ Video 4 for
1
each of the camera's sensors. The settings below will apply to that sensor only.
Click 'Apply' to save the settings before changing to another video source.
Live Video Channel Setup - The video can be configured to various settings with a combination of codec and
2
resolution. The camera performance should be considered when setting multiple channels, as the performance
of the camera will be affected.
H.265 (HEVC) codec with a higher bitrate may cause unstable live streaming or reload the webpage.
Codec - Choose the video codec. Depending on the selected codec, the subcategories may vary.
3
Description - Enter additional description for the selected channel. There is a limit maximum of 30
4
alphanumeric characters, including spaces.
Resolution - Select video resolution.
5
Available Frame Rate may vary even if the same codecs are in use.
2560x1440
QFHD
(4M)
3840x2160 2560x1440 1920x1080 1280x720
Frame Rate - Select the maximum Frame Rate.
6
Available Frame Rate may vary even if the same codecs are in use.
1080p/i 720p/i SVGA
800x600
768x432
4CIF
(0.3M)
704x576
768x432 640x480
704x480
18
640x360
VGA CIF
(0.2M)
352x288
640x360
352x240
