Digital Watchdog MEGApix Flex DWC-PVX20WATW User Manual page 42

Setup - Network Setup
HTTP Action
1
2
3
4
General Setting - Enable or disable the camera to send out an HTTP action when an event occurs. When
1
enabled, the camera can notify a monitoring software using HTTP protocol.
Account information - Set the RTSP time out.
2
Description: Enter a short description to be
HTTP Action Server: Enter the HTTP address of the receiving server. This is the server that will receive the
HTTP action notification from the camera.
PORT: Enter the port number for the receiving server.
User ID: Enter the user ID information for the receiving server.
Password: Enter the password information for the receiving server.
Message - Enter the default message that will be included with the alert.
3
Click 'Apply' to make the above setting effective.
4
Click this button when completing the setup of each channel.
42
