Digital Watchdog MEGApix Flex DWC-PVX20WATW User Manual page 29

Setup - Camera Setup
Camera Backlight Settings
2
3
4
This is a feature used for problematic light conditions where the contrast from light to dark areas is very high.
VIN Source - Each of the camera's sensors must be set up separately. Select between Video 1 ~ Video 4 for
1
each of the camera's sensors. The settings below will apply to that sensor only.
Click 'Save' to save the settings before changing to another video source.
WDR (Wide Dynamic Range) - Enable or disable the WDR function for the camera.
2
WDR Level - When enabled, set the WDR level from low, middle and high. The default level is 'middle'.
3
Click 'Save' to save the current settings.
3
Click 'Cancel' to return to the previous setting.
Click 'Default' to settings to the factory defaults.
29
